Ball Trough Switches
(Viewed from underside of playfield to show locations)
5070-06258-00
01-8652 5647-12073-00
Diode
Bracket
Microswitch
5647-09957-00
Microswitch
5070-06258-00
Diode
Jo4---~-
A-8645
Sw Wire
&
Brkt
A-8643
Mounting Plate
A-5844-44
Sw Wire
&
Brkt
5647-09957-00
Microswitch
RM-21-03
Tubing
•
8-10686-1 Knocker Assembly
Item Part Number
1 A-5387
a) 02-2653
b) 03-6013
2 B-7409-2
3 AE-23-800
4 01-8-508-T
5 23-6420
6 4008-01017-06
7 H-11835
8 03-7067-5
•
2-19
Description
Coil Plunger Assembly
Coil Plunger
Bell Arm Ext.
Mtg. Bracket Assembly
Coil Sub-Assembly
Coil Retaining Bracket
Rubber Grommet
Mach. Screw, 8/32 x 3/8
Knocker Cable
Coil Tubing
Ball Trough Switches
Knocker
