SOUND MODULE
COMPONENT PARTS LIST
REFERENCE
ITEM DESIGNATION
1 A8 (see note 1)
2 U1
3 U2
4 U3
5 U10
6 U5
7 U6
8 U8
9 U9
10 Q1
11 CR1,2
12 SW1
13 C12
14 C2
15 C16
16 C3
17 C18, 19
18 Y1
19 J2
20 J1
21 R9
22 R8
23 R7
24 R1
25 R21,22,23,24
26 R6
27 R3, 14, 15, 16,
17,18,19,25
28 R2
29 R10
30 R4
31 R5,20
32 RT1
33 C23
34 C15
35 C7
36 C8
37 C5,13
38 C9, 1,14,6
39 C4, 22,17,21,
20,24
40 XU10, XU4
41 XU1, XU2, XU3
42 Used with 43
43 Used with 42
44 H.S for U9
45 Used with C15
46 TP1, 2, 3, 4, 5, 6
47 Use with 44, 9
48 Jumper, B
BALLY
PART NO.
AS-3022-12
E-620-124
E-620-29
E-620-125 (E620-128)
E-620-30
E-620-33
E-620-5
E-620-126
E-620-127
E-585-31
E-587-6
E-658-1
E-586-118
E-586-130
E-586-83
E-586-120
E-586-121
E-744-5
E-736-2
E-736-15
E-105-196
E-105-211
E-105-303
E-105-230
E-105-238
E-105-239
E-105-185
E-105-245
E-105-252
E-105-225
E-105-285
E-599-16
E-586-122
E-586-123
E-586-124
E-586-129
E-586-90
E-586-89
E-586-85
E-712
E-712-1
LSPR-00632-1106
N-00632-2112
E-682-8
E-647-5
P-5399
M-1834
DESCRIPTION
PWB Module Complete
Sound Chip AY-3-8910
PIA,6820/21
CPU, 6808 (6802 Note 3)
Ram, 6810 (Note 3)
Hex Inverter 4049B
Quad 2 Input 4011 B
Amp, LM3900
Power Amp, TDA 2002
Transistor, 2N3904
Diode, 1N4004
Switch
Cap .. 2MF ±20% Y5P, 16 V.
Cap . .47 ±20%
Cap. 470 PF 50 V.
Cap. 68 PF, ±20% 1K
Cap. 27 PF, ±20% 1K
Crystal, 3.579545 MHZ
Connector, Wafer, 2 Pin KK156
Connector, Wafer, 15 Pin KK156
Resistor, 1 Ohm,
1f4
W, 5%
Resistor, 2.2 Ohm,
%
W, 5%
Resistor, 220 Ohm,
%
W, 5%
Resistor, 1 K,
1/4
W, 5%
Resistor, 3.3K. Ohm,
%
W, 5%
Resistor, 4.7K.,
1f4
W, 5%
Resistor, 10K.,
%
W, 5%
Resistor, 30K.,
1f4
W, 5%
Resistor, 180K.,
1f4
W, 5%
Resistor, 200K.,
1f4
W, 5%
Resistor, 1M,
%
W, 5%
Potentiometer 1K
Cap .. 001 ±20% 2SF
Cap. 4700 MF @ 25 V.
Cap. 470 MF
@
6.3 V
Cap. 470 MF
@
16 V.
Cap. 1 MF@50V.
Cap .. 1 MF
Cap .. 01 MF
Socket, 24 Pin
Socket, 40 Pin
Bolt, 6 x 32
X 3/8
Nut, 6 x 32
Heat Sink, 6030BTT
Ty Rap
Test Point
Thermal Grease
22 AWG Wire, Solid Tinned
Schematic
W-1211 c
NOTE1:
When ordering specify name of game.
NOTE
2: Order replacement memory chip U4 specifying name of game and part no. stamped on chip.
NOTE
3: When using item 4,6808 you must use item 5, 6810 and the "8" jumper. When item, 6802 is available
delete item 5 and use "A" jumper.
