SOLENOID IDENTIFICATION
10 RIGHT SLINGSHOT
11 GATE
12 COIN LOCKOUT DOOR
13 KI RELAY (FLIPPER ENABLE)
.
GAME #1217 FRONTIER (FIGURE V)
SOLENOID IDENTIFICATION TABLE
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
Self
Test
#
SOLENOID IDENTIFICATION
01 OUTHOLE
02 KNOCKER
03 3 DROP TARGET RESET
04 SAUCER
05 DROP TARGET RESET (INLlNE)
06 LEFT THUMPER BUMPER
07 RIGHT THUMPER BUMPER
08 BOTTOM THUMPER BUMPER
09 LEFT SLINGSHOT
,
t
i
I
Switch
Self
Test
#
DESCRIPTION
01 30 POINT REBOUND (4)
02 RIGHT OUT
03 RIGHT FLIPPER FEED
04 LEFT FLIPPER FEED
05 LEFT OUT
06 CREDIT BUTTON
07 TILT (3)
08 OUTHOLE
09 COIN III (RIGHT)
10 COIN I (LEFT)
11 COIN II (MIDDLE)
12 SAUCER
13 "P\'
ROLLOVER
14 "B" ROLLOVER
15 "C" ROLLOVER
16 SLAM (2)
17
18
19
20
Switch
Self
Test
#
DESCRIPTION
21 3RD INLINE DROP TARGET
22 2ND INLINE DROP TARGET
23 1ST INLINE DROP TARGET
24 GRIZZLY TARGET
25 SAUCER ROLLOVER BUTTON
26
27 SPINNER
28
29 LEFT TARGET
30 CENTER TARGET
31 RIGHT TARGET
32
33 BOTTOM SIDE DT
34 MIDDLE SIDE DT
35 TOP SIDE DROP TARGET
36 RIGHT SLINGSHOT
37 LEFT SLINGSHOT
38 BOTTOM THUMPER BUMPER
39 RIGHT THUMPER BUMPER
40 LEFT THUMPER BUMPER
NOTE: SLINGSHOT & THUMPER BUMPER COILS
WILL BE ENERGIZED WHEN SWITCH IS MADE.
17
