c.
FRONT DOOR GAME ADJUSTMENTS
High Score Feature Adjustments:
The game is designed to award an extra ball (option) or a free game at each of three score
levels. The recommended levels are on the score card in the game.
Any level from 10,000 to 9,999,000 can be set, as desired. It is also possible to reset or turn off
(00) any or all of the levels, if desired.
1. Push and release Self-Test button (See Figure III) at one second intervals approximately
six times or until identification number 01 appears on the 'Match/Ball in Play' display.
2. The number on the Player Score Displays is the score level.* It can be increased, if
desired, by holding the credit button in. Todecrease the score level, hold the credit button in
and depress and release the Self-Test button. Release the credit button when the desired
number appears. Note that the level changes 10,000 points at a time. If the number '00' is
left on the displays, the high score feature is eliminated for that level.
3. Repeat steps 1 and 2 for the second and third score levels. The identification numbers
'02' and '03' on the Match/Ball in Play display are for the second and third levels,
.respectively.
High Score to Date and 10,000,000 Feature:
The game is designed to award free games when 'High Score to Date' is beat, or if the player
exceeds 10,000,000 points.
It is recommended that the level, which will build with play, be periodically reset to the factory
recommended level to encourage game play. The adjustment procedure is the same as for the
High Score Feature Adjustment, Steps 1 and 2. Continue pushing the Self-Test button until the
identification number '04' appears on the 'Match/Ball in Play' display and then do Step 2.
Any level from '00' to 9,990,000 can be set as described. It is to be noted that '00' does NOT turn
off the feature, as it does on High Score feature. The feature is turned off by self test position 19 as
discussed under 'Back Box Game Admustrnents.
SELF TEST SETUP FOR 16-19:
Toset up positions 16-19 push and release self test button till 16 shows on match/ball in play. Now
pulse replay button for recommended setup from "00" thru "03:' Repeat for positions 17,18 or 19.
'Can be quickly set to '00' by pressing S33 on the MPU assembly in the back box or Coin Chute switch #3. (See Figure III).
,-
"
