#906 - German Model Only
GAME ADJUSTMENTS
7.
(G)
PLAYFIELD PANEL POST ADJUSTMENTS:
Posts that control left an~ right out lane opening on panel (see
panel sketch FO-320) can be moved to make access to outlanes
easier or harder for ball to enter"
Easier entry will "decrease" playing time and scoringo
Harder entry will "increase" playing time and scoring.
BELL ADJUSTMENT
PLUG:
Located on back box lite insert. This plug provides positions
to ring bell for "100" point scores, "lOaD" point scores, or
both "100
&
1000" point scores,
HI-SCORE ADJUSTMENT PLUG:
Located on back box lite insert. This plug provides a wide
range of coverage at which hi-score "credits" can be scored.
(see "score adjustment card" in back box for plug positions).
1ST COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to give "1 play!' for multiple coins" (position 1)
or "2 plays" for single coin" (position 2) thru the "1st
coin chute
ll
•
MATCH FEATURE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to turn match feature "on" or "off".
BALLS PER GAME ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to operate game on "5 ball" or "3 ball" playo
HI-SCORE FEATURE ADJUSTMENT PLUG:
Located on front cabinet mounting boardo This plug provides
positions to turn hi-score "credit" feature "on" or "off".
2ND COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board. This plug provides
positions to give "I play for single coin" (position 1) or
"multiple plays for single coin" (position 2) thru the 2nd coin
chute" Note: When plug is set for "multiple plays for single
coin", brown-white (male plug) wire on the 3rd coin chute
adjustment plug must be put in "numbered position" for amount
of plays desired. (4-5)
3 'RD COIN CHUTE ADJUSTMENT PLUG:
Located on front cabinet mounting board" This plug provides
positions to give "multiple plays for single coin" thru the
3rd coin chute. Note: When setting this plug, use yellow-
brown (male plug) wire in "numbered position" for amount of
plays desired. (10-12)
