HIGH SCORE TO DATE
Depressing the High Score Reset switch in the game over
mode changes the current high score to date (Function 12) to
the value of the backup high score to date (Function 13).
The value of function 13 can be changed to any multiple of
to,ooo
points. With the value of function 13 set to zero, the
high score to date feature is disabled. To change the backup
high score to date, proceed as follows:
I. If
not already in test 04, enter test 04 in one of the
following ways:
a. From the game over mode,
set the AUTO-
UP/MANUAL-DOWN switch to AUTO-UP and
depress the ADVANCE pushbutton.
b. From diagnostics, set the AUTO-UP/MANUAL-
DOWN switch to AUTO-UP and depress the
ADVANCE pushbutton to advance the diagnostics
to test 04.
2. Set the AUTO-UP/MANUAL-DOWN switch to the
desired position and operate the advance pushbutton
until function 13 is indicated on the ball in play display.
The backup high score to date is indicated in the Player 1
display.
3. To change the backup high score to date, proceed as
follows:
a. To lower the backup value set the AUTO-
UP / MANU AL-DOWN switch to MANU AL-
DOWN.
To raise the backup value, set it to AUTO-UP.
b. Operate the credit button until the desired backup
value is indicated on the player
I
display.
NOTE
To disable the high score to date feature, set function
13 to zero.
4. If no further game adjustments are required, turn the
game OFF and back ON to return to the game over
mode.
REPLAY SCORES
There are four possible replays awarded from scoring. The
factory setting for the first three replay scores are provided in
Table
I
and on the instruction booklet inside the game. The
fourth replay is disabled. Replay I is function 14, replay 2
function 15, replay 3 function 16, and replay 4 function 17.
Replay points can be increased or decreased by any multiple
of 10,000 points. To make changes to replay points, proceed
as follows:
I.
If
not already in test 04, enter test 04 in one of the
following ways:
a. From the game over mode,
set the A UTO-
UP/MANUAL-DOWN switch to AUTO-UP and
depress the ADVANCE pushbutton.
b. From diagnostics, set the AUTO-UP/MANUAL-
DOWN switch to AUTO-UP and depress the
ADVANCE pushbutton to advance the diagnostics
to test 04.
2. Set the AUTO-UP/MANUAL-DOWN switch to the
desired position and operate the ADVANCE push-
button until function 14 is indicated on the ball in play
display.
3. To change the score for Replay I, proceed as follows:
486
a. To raise the replay points,
set the A UTO-
UP/MANUAL-DOWN switch to AUTO-UP.
To lower the replay points, set it to MANUAL-
DOWN.
b. Operate the Credit button until the desired value is
indicated on the Player
I
display.
NOTE
To disable any replay point, raise or lower the value
in the Player
I
display to zero.
4. With the AUTO-UP/MANUAL-DOWN switch set to
AUTO-UP,
depress the ADVANCE pushbutton one
time. Function
IS
is indicated on the ball in play display
and the current value of replay 2 is indicated on the
Player
I
display.
S.
To change the score for replay 2, perform steps 3a and
3b.
6. Repeat step 4 to display Function 16 on the ball in play
display and the replay 3 score in the Player
I
display.
7. To change the score for replay 3, perform steps 3a and
3b.
8. Repeat step 4 to display Function 17 on the ball in play
display and the replay
4
score on the Player 1 display.
9. To change the replay 4 score, perform steps 3a and 3b.
10.
If
no further game adjustments are required, turn the
game
OFF
and back ON to return to the game over
mode.
MAXIMUM CREDITS
Maximum credits is the number of credits that can be posted
(by putting coins in the game or free credit awards) before
the coin lockout relay is released. Maximum credits is
Function 18 and the factory setting is 20. Maximum credits
may be set to any value from 1 to 99; setting maximum
credits to zero sets the game to a free play mode.
To make changes to maximum credits, proceed as follows:
I.
If
not already in test 04, enter test 04 in one of the
following ways:
a. From the game over mode,
set the A UTO-
UP/MANUAL-DOWN switch to AUTO-UP and
depress the ADVANCE pushbutton.
b. From diagnostics, set the AUTO-UP/MANUAL-
DOWN switch to AUTO-UP and depress the
ADVANCE pushbutton to advance the diagnostics
to test 04.
2. Set the AUTO-UP/MANUAL-DOWN switch to the
desired position and operate the ADVANCE push-
button until Function 18 is indicated on the ball in play
display.
3. To raise the maximum credits set the AUTO-
UP/MANUAL-DOWN switch to AUTO-UP.
To lower the maximum credits set it to MANU AL-
DOWN.
4. Operate the Credit button until the desired number of
maximum credits is indicated on the Player I display.
5. If no further game adjustments are required, tum the
game OFF and back ON to return to the game over
mode.
