486
PLA YFIELD (con't)
Pin Wire Color
Function
SP2ISJ2 - PLA YFIELD LAMPS
(White-24 Pin)
I
Yellow
2
Yellow- White
3
Yellow-Brown
4
Yellow-Red
5
Yellow-Orange
6
Yellow- Black
7
Yellow-Green
8 Yellow-Blue
9
Yellow- Violet
10
N/C
II
Red-Brown
12
Red-Black
13 Red-Orange
14
Red- Yellow
15
Red-Green
16
Red-Blue
17
Red-Violet
18
Red-Gray
19-24 N(C
6 3 VAC Display
6.3 VAC Display
Lamp Column
#
1
Lamp Column
#
2
Lamp Column
#
3
Lamp Column
#
4
Lamp Column
#
5
Lamp Column
#
6
Lamp Column
#
7
Not Used
Lamp Row
#
I
Lamp Row
#
2
Lamp Row
#
3
Lamp Row
#
4
Iarnn Row
#
5
Lamp Row
#
6
Lamp Row
#
7
Lamp Row
#
8
Not Used
8P3/8J3 - PLAYFIELD SOLENOIDS,
SPECIAL
SWITCHES (Black) (24 Pin)
1
Red
2
Black
3 Blue-Violet
4 Blue-Gray
5 Orange-Brown
6 Orange-Red
7 Orange-Black
8 Orange-Yellow
9 Orange-Green
10 N/C
11 Blue-Brown
12
Blue-Red
13 Blue-Orange
14 Blue-Yellow
15 Blue-Green
16 N/C
17
Gray-Brown
18
Gray-Red
19 Gray-Orange
20 Gray-Yellow
21
Gray-Green
22 Gray-Blue
23 Gray-Violet
24
Gray-Black
Coil B+
Ground (Special Switch
Common)
Right Flipper Coils
Left Flipper Coil
Left Jet Bumper Sw.
Right Jet Bumper Sw.
Lower Jet Bumper Sw.
Right Kicker Sw.
Left Kicker Sw.
Not Used
Left Jet Bumper Coil (18)
Right Jet Bumper Coil (17)
Lower Jet Bumper Coil (19)
Right Kicker Coil (20)
Left Kicker Coil (21)
Not Used (22)
Ball Release Coil (1)
5-Bank 1-3 Reset Coil
(2)
5-Bank
4-5
Reset Coil (3)
3-Bank Reset Coil (4)
Eject Hole Coil (5)
"FLASH" Lights (6)
Not Used (7)
Not Used (8)
NOTE: Number in parentheses ( ) in
8P3
Function
column is the solenoid number readout in test 02.
36
Pin Color
INSERT BOX
Function
9Pl/9Jl
- INSERT DOOR LAMP CONNECTOR
(Black-IS Pin)
1
2
3
4
5
6
7
8
9
10
II
12
13
14
15
Yellow
Yellow- White
N/C
Yellow
Yellow- White
Y
ell ow- Violet
Yellow-Gray
Red-Brown
Red-Black
Red-Orange
Red-Yellow
Red-Green
Red-Blue
Red-Violet
Red-Gray
6.3 VAC Display Lamps
6.3 VAC Display Lamps
Not Used
6.3 VAC Display Lamps
6.3 VAC Display Lamps
Lamp Column # 7
Lamp Column #
8
Lamp Row
#
1
Lamp Row
#
2
Lamp Row
#
3
Lamp Row
#
4
Lamp Row
#
5
Lamp Row
#
6
Lamp Row
#
7
Lamp Row
#
8
9P2I9J2 - PLAYER I KEEP ALIVE
Brown- White
Anode Keep Alive
9P3/9J3 - PLAYER 2 KEEP ALIVE
Brown-White
Anode Keep Alive
9P4/9J4 -
PLAYER 3 KEEP ALIVE
Brown-White
Anode Keep Alive
9PS/9J5 -
PLAYER 4 KEEP ALIVE
Brown-White
Anode Keep Alive
SOUND BOARD
lOPlIIOJl
- POWER INPUTS
1
Gray
18.7
VAC
2-4
N/C
Not Used
5
Gray-White
18.7
VAC
c.r.
6
N/C
Not Used
7
Key
Key
8
N/C
Not Used
9
Gray
187
VAC
IOP2IIOJ2 - SPEAKER OUTPUT
1
2
3
4
N/C
Red
Black
N/C
Not Used
Speaker
+
Speaker Com
Not Used
IOP3/l0J3 - SOUND SELECT INPUTS
1
2
3
4
5
6
7
8
9
Key
Brown-Red
Brown-Black
Brown-Yellow
Brown-Orange
N/C
Brown-Green
N/C
NjC
Key
Sound (10)
Sound (9)
Sound (12)
Sound (11)
Not Used
Sound (13)
Not Used
Not Used
