Unique Parts
Part Number
Description
Part Number
Description
A-11657-2
Ball Poper Assembly
A-15403-1
Flipper Return Frame Assy.
l.
A·11658-1
Switch & Diode Assembly
A-1S403-2
Flipper Return Frame Assy. R.
A·1273B-50005
WPC Sound Board
A·15404
Reel Enter Ramp Assembly
A-12742-50005
WPC CPU Board
A-15405
Fish Rod & Reel Cover Assembly
A-13204·50005
Bottom Arch Assembly
A-15412
Right Wire Ramp Assembly
A-13769-50005
Playfield & Insert Assembly
A-15413
Lett Wire Ramp Assembly
A-13769A-50005
Mini Playfield
&
Inserts
A-15415
5-Lamp Board Assembly
A-14376-50005
Backbox Assembly
A·15421-1
Playfield Slide Assembly, Left
A-14945
Fish Reel Unit Assembly
A-15421-2
Playfield Slide Assembly, RighI
A-14947
Catapult Assembly
A-15457
5-Lamp Board Assembly
A-15055
Boat Ramp Assembly
A-15470
3-Lamp Board Assembly
a
A-15069
Ball Guide Assembly
A-15471
5-Lamp Board Assembly
A-1S10B
Ball Guide Assembly
A-154gB
Speaker Display Assembly
A-1S109
Boat Unit Assembly
A-15506
Playfield Plastic
&
Bracket Assy.
A-15130
FishtReel Handle Assembly
A-15531
Wire Ramp Cover Assembly
A-1S177
Ball Guide Assembly
A·15532
Fish Reel Handle & Parts Assy.
A-1517B
Ball Guide Assembly
A-15540
Boat Flap
&
Decal Assy.
A·15179
Ball Guide Assembly
A-15544-
Playfield Plastic Set Assembly
A-15180
Ball Guide Assembly
A-15565
5-Lamp Board Assembly
A-151B2
Ball Guide Assembly
A-15579-1
Cashbox Assembly
A-1S208
Back Panel Assembly
A-15585
Plate - Fish Protect
A-15211
1-Bank Drop Target Assembly
A-15632
Fish Panel Cover Assembly
A-15304
Coil Unit Assembly
A-15658-6
Oblong Target Assy. Yellow
A-15306
Fish Panel Assembly
A-15689
Support Bar Assembly
A'15330-2
Stationary Target Assembly
A-15713
Fish Assembly
A-15333
3-Lamp Board Assembly
A-15741
Stationary Target
&
Decal Assy.
A-15334
4-Lamp Board Assembly
A-15749
Coil
&
Bracket Assembly
A-15335
5-Lamp Board Assembly
A-8552-5000S
Backglass Assembly
A-15336
6·Lamp Board Assembly
A-9361-R-11
Ball Eject Assembly, Right
A·15337
15-Lamp Board Assembly
A-15338
5-Lamp Board Assembly
A-15339
3-Lamp Board Assembly
02-4252-40
F·F Spacer
2-1/2"
A-15373
Ball Guide Unit Assembly
02-4311-3
Mounting Post
4-3/B"
A-15401
Spin Target Light Unit Assembly
02-4608
Double Bumper Post
FISH TALES 2-37
