A·9361·R·11
Ball Eject Assembly
I
I
I
I
J
-"
....
-"
I ,-
•....
Associated Parts:
•..
Item Part Number
Description
Item Part Number
Description
1.
A-6949-R
Spring Plate Assembly
9.
B-9362-R-3
Coil & Bracket Assembly
2.
A-8268
Mounting Bracket Assembly
a) 8-7572-1
Bracket & Stop Assembly
3.
A-7471-R
Eject Cam Assembly
b) 01-8-508-S
Coil Retaining Bracket
4.
A-8050-2
Coil Plunger Assembly
c) 4006-01017-06 Mach. Screw, 6-32 x 3/8
a)
02-3407-1
Coil Plunger Assy.,
2-5/16"
d) 4406-01119-00
Nut, 6-32 ESN
b) 03-8085
Armature link
e) AE-26-1200
Coli Assembly
c) 20-8716-5
Roll Pin, 1/8 x
7/16"
f)
03-7066
Coil Tubing
5.
10-320
Eject Spring
10.
10-128
Spring
6.
12-6227
Hairpin Clip (2)
11.
03-7351-1-9
Eject Shield
7.
4700-00030-00 Flatwasher,
17/64 xll2
x 15ga. (1)
8.
4700-00103-00 Flatwasher,
17/64
xll2
x 28ga. (1)
FISH TALES
2-20
