A-B039-3
Outhole Kicker Assembly
I'
..••.
I
....
I
I
r
,{
,
....
,
i,
....
---
I I
4
---
I
--
"...
I
I
I
I
I
I
I
t
I
I
I
I
I I
I
I
I
Item Part Number
Description
1.
A-6378
Mounting Plate Assembly
2.
03-7066
Coil Tubing
•
3.
A-6889
Kicker Lever Assembly
4.
A-8038
Coil Stop Assembly
5.
AE-27-1200
Coil Assembly
6.
03-7176-1
Striker RIng
7.
10-101-4
Spring-Reset
8.
20-8712-25
"E" Ring, 1/4" Shaft
9.
4006-01 003-03 Mach. Screw, 6-32 x 3/16"
10.
A-8335
Coil Plunger Assembly
a)
02-2364
Coil Plunger
b) 20-8716-5
Roll Pin,
1/8
x
7/16"
c)
01-4251
Ball Return Link
FISH TALES 2-18
