Page 63 - Fish Tales

" .••.
1 ••••
I ... •• ...
I .
I ....•..
..• .'1
I
I
I
I,
I
I
I
I
I
I
I
I
I
I
I
I
I
I
1
I
I
1,
I
I
I
I
I
1
I
I
I
I
I
I
I
I
I
I
I
\
I
I....
.••.. •....• •...<, I
.••. ,~
,
I ,
, I
I I
~ r
B-9414-3 A-9415-2
Jet Bumper Assembly Jet Bumper Coil Assembly
Item Part Number Description Item Part Number Description
1. A·4754 Bumper Ring Assembly 1. B-7417 Bracket & Stop Assembly
2. 03-6009-AS Bumper Base, White 2. 01-1747 Coil Retaining Bracket
3. 03·6035·4 Bumper Wafer. Red 3. 01-5492 Armature Link, Steel
4. 03-7443-5 Bumper Body. White 4. 01-5493 Armature Link. Bakelite
5. 10-7 Spring 5. 02-3406-1 Coil Plunger
6. 24-8776 Socket-Wedge Base 6. 10-326 Armature Spring
7. 24·8768 Bulb #555 (6.3V.• O.25A.} 7. AE-26·1200 Coil Assembly
8. 4006-01017-04 Mach. Screw, 6-32 x lW
Associated Parts: 9. 03-7066 Coil Tubing
8. 03-8254-9 Jet Bumper Cap,
Trans. Red (3)
FISH TALES 2·15
- --,
