Press the Enter button to activate the Adjustments Menu, once the menu name is shown under the Main
Menu. Then, use the Up or Down button to cycle through the Adjustments Menu selections.
Press the
Enter button to activate a selection.
Press the Up or Down button to cycle through the available
adjustments.
Press the Enter button to activate an adjustment. When an adjustment is activated, the
setting value begins to flash. Use the Up or Down button to raise or lower the setting value. Press Enter
to lock in the value. If a mistake is made, press the Escape button while "Saving Adjustment Value" is
displayed. The new value is ignored and the original value is retained. Press the Escape button to return
to the Adjustments Menu. Press
it
again to return to the Main Menu.
A. Adjustment Menu
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D Adjustments
A.S
Printer Adjustments
(optional board required)
A.1 Standard Adjustments
A.1 01
A.1 02
A.1 03
A.1
04
A.1
05
A.1
06
A.1 07
A.1 08
Balls
Per
Game
A "game" is defined by specifying the number of balls to be played. Range:
1
to
10.
Tilt
Warnings
The number of total actuations of the plumb bob mechanism that can occur before the
game is ''tilted''. Range:
i
to
10.
Maximum
Extra Balls
The number of Extra Balls that a player may accumulate. Range:
0
to
10.
Maximum Extra Balls/Ball
In
Play
The number of Extra Balls to be awarded per ball in play. Range:
Off
No maximum number of Extra Ball per ball in play.
1-10
1
through
10
Extra Balls per ball in play.
Replay System
The type of replay system to be used. Choices:
Fixed -
Auto%-
Replay value
is
set and does not change during game play.
Replay starting value
is
set
but
changes every
50
games to comply
with the percentage of replays desired.
Replay Percent'"
The percentage of replays the players are able to earn when Auto Replay is used. Range:
5% to 50%.
Replay
starr'
Replay start value when Auto% Replay is used. Range:
15,000,000
to
250,000,000.
Replay Levels'"
The number of replay levels used by the Auto% Replay mode. The range of this setting is
1
through
4.
When two replay levels are chosen, the second replay level is automatically
adjusted to twice the starting replay level. When three of four replay levels are chosen,
their values are automatically adjusted to three or four times the starting replay level.
*For Auto% Replay.
•
