10. Move the game into the desired location; recheck the level and pitch angle of the playfield.
11. Be sure the correct number of ball are installed. FISH TALES uses four balls; three balls in play and
one captive ball.
12. Remove foam from the captive ball mechanism. Grasp the foam at the bottom of the captive ball trough
and pull it out of the mechanism.
13. Install playfield mylars if desired.
Note: The FISH TALES pJayfield is coated with a covering called Diamond Plate™ and does not
require a protective mylar. However, mylars can be purchased through your local Williams Distributor.
Specify part number 03.a674-1 for full playfield mylar.
14. To attach the line cord, remove the envelope stapled to the inside of the cabinet (near the cashbox).
Remove the four Phillips-head screws that mount to line cord cover plate to the rear cabinet. Match the
prongs on the plug with the holes in the receptacle, and push the line cord securely into place. Make sure
the cord is aligned with the indentation on the cover plate (indentation should point toward bottom of the
cabinet). Remount line cord cover plate. If desired, four tamper resistant screws have been provided in an
enevlope marked "Security Screws" (located in the cashbox) to remount cover plate.
•
Tamper·resistant Scmw
15. Clean and reinstall the playfield cover glass. Prepare the game for player operation.
FISH TALES 4-4
