1. Remove all cartons, parts, and other items from the shipping container, and set them aside.
2.
Place the cabinet on a support and attach rear legs using leg bolts. Leg levelers and leg bolts are
provided among the parts in the cash box.
3.
Attach the front legs (after installing leg levelers), using leg bolts.
•
Pinball Game Assembly Instructions
This is a four ball game.
Three balls in play and one captive ball.
Cabinet Dimensions
Approx.
Length:
SS"Approx.
Width: 26" Approx.
Height: 85"
Weight: 285 Ibs
,
,
I
I
I
,
•.•.'\
I
I
/
\
,
'//
\
I
t- /
....
I
/"1
•.•. ..-
'" L
....
,<
I, --::.. ...-----
· 1
\ 1/ '"
»:
I
-- -'*:.....
I
--------_ . J
Detail View·
Leg Leveler
Approx Playfield
Pitch Angle:
~:-7~re~
See Delail View:'
\,
,
'
.•
,
.•
_,
Leg
leg Leveler
Nul
4. Reach into the cabinet and backbox and ensure that the interconnecting cables are not kinked or
pinched. Be careful to avoid damaging wires at any stage of the assembly process.
5. Raise the hinged backbox upright and latch it into position.
Unlock the backbox, and remove the
backglass.
Remove the shipping block holding the Insert Board. Unlatch and open the Insert Board.
Carefully lift up the Speaker Panel and lay it down on the playfield glass. (Be careful not to damage the Dot
Matrix Display/Driver.) This allows access to the bolt holes used for securing the backbox upright. To
secure the backbox, install the washer-head mounting bolts through the bottom holes of the backbox into
the threaded fasteners in the cabinet. Close and latch the Insert Board. Replace the Speaker Panel.
Reinstall the backglass, and lock the backbox.
If the Fish Panel on the top of the backbox Is removed, be sure to slide the
cover plate over the cable hole and screw It Into place with the #8 torx
bit.
&
CAUTION
FAILURE
TO
INSTALL
the backbox mounting hardware properly can cause personal injury.
NEVER TRANSPORT
a pinball game with the hinged backbox erect.
Always lower the backbox
forward onto the playfield cabinet on a layer of protective material to prevent marring or damage and
possible personal injury.
FISH TALES 4·2
