Dot Matrix Controller Board
lnterboard Wiring
J601, 34-pin Ribbon Cable (data) Tolfrom J202; J903; J506
J602, 26-pin Ribbon Cable (data) To/from J201
J603, 14-pln Ribbon Cable (data) To/from Dot Matrix Display/Driver
f
J604 -1
J604 - 2
J604 - 3
J604 - 4
J604 - 5
J604 - 6
J604 -7
J604 - 8
J60S -1
J605 - 2
J605 - 3
J60S - 4
J605 - 5
J606 -1
J606 - 2
J606 - 3
J606 - 4
J606 - 5
J606 - 6
J606 -7
Orange (-125V) to Display/Driver pin 1
Slue (-113V) to Display/Driver pin 2
N/C
Black (Grd) to Display/Driver pin 4
Black (Grd) to Display/Driver pin 5
Gray (+5V) to Display/Driver pin 6
Gray-Yellow (+12V) to Display/Driver pin 7
Brown (+62V) to Display/Driver pin 8
White (80VAC) from xformer secondary
White (80VAC) from xtormar secondary
Violet (1OOVAC) from xformer secondary
N/C
Violet (100VAe) from xformer secondary
Black (Grd) loop from J606-3
NlC
Black (Grd) from Power Driver Srd J117-3
Gray (+5V) loop from J606-5
Gray (+5V) from Power Driver Brd J117-4
Gray-Yellow (+12V) loop from J606-7
Gray-Yellow (+ 12V) from Power Driver Brd J117-2
J607 - Not Used
J608 - Not Used
