Power Driver Board Interboard Wiring Continued ..•
J116 -1 NiC
J116 - 2 Gray-Yellow (+ 12V) to coin door
J116 - 3 Black (Grd) to coin door
J116 - 4
N/C
J123 -1 N/C
J123 - 2
N/C
J123 - 3 N/C
J123·4 N/C
J123 -
5
N/C
•
J117 - 1
N/C
J124 -
1
Blue-Brown (sol. 25 drive) to Insert Brd & Hood fish Imps
J117 - 2 G
ra
y- Yellow (+12 V) to Dot Matrix Controller J 606-7 J124 • 2
N/C
J117 -
3
Black (Grd) to Dot Matrix Controller J606-3
J124 - 3 Blue-Orange (sol. 27 drive) to Insert Board flash lamp
J117 - 4 Gray (+5V) to Dot Mat
rlx
Cant roller J 606-5
J124 -
4
N/C
J124 -
5
N/C
J118 -1
N/C
J118 - 2 GraY-Yellow (+12V) to Oplo Sw. Brd &
J118 - 3 Black (Grd) to
opto
Board
J118 - 4 NlC
Molar EMI 8rd
J125 -1
N/C
J125· 2 N/C
J125 - 3 Black-Orange (sol. 19 drive) to Insert Board flash lamps
J125 -
4
N/C
J125 -
5
Black-Yellow (sol. 20 drive) to Insert Board flash lamps
J125 - 6 Blue-Green (sol. 21 drive) to Insert Board flash lamps
J125 -7 Blue-Black (sol. 22 drive) to Insert Board flasl1lamps
J125 - 8 Blue-Violet (sol. 23 drive)
10
Insert Board flash lamp
J125 -
9
WC
J119 - 1 Violet-White (6. 8VAC) G .1. to coi n door
J119 - 2
N/C
J119 -
3
Violet (return) G.1. to coin door
J120
-1
J120 -
2
J120 - 3
J120 -
4
J120·5
J120 - 6
J120 -
7'
J120 - 8
J120 - 9
J120 -10
J120 - 11
J121 •
1
J121 - 2
J121 -
3
J121 -
4
J121 -
5
J121 - 6
J121 -7
J121 - 8
J121 - 9
J121 -10
J121 -11
Brown (return) G.I. to Insert Board
Orange (return) G.I. 10 Insert Board
N/C
NlC
Green (return) G.1. to Insert Board
N/C
White-Brown (6.8VAC) to Insert Board
White-Orange (6.8VAC) to Insert Board
N/C
White-Green (6.8VAC) to Insert Board
N/C
J126·'
J126 - 2
J126 -
3
J126 -
4
J126 - 5
J126 -
6
J126
-7
J126 -
8
J126 - 9
J126 -10
J126 • 11
J126 - 12
J126 -13
Black-Brown (sol. 17 drive) to pIayfield fJashlamp
Black-Red (sol. 18 drive) to playfield flashlamp
Black-Orange (sol. 19 drive) to playfield flashlamp
Black-Yellow (sol. 20 drive) to playfield flashlamp
Blue-Green (sol. 21 drive) to playfield flashIamp
Blue-Black (sol. 22 drive) to pJayfieJd flashlamp
Blue-Violet (sol. 23 drive) to playfield flashlamp
NlC
NlC
N/C
N/C
NlC
N/C
NlC
Orange (return) G.l.lo hood
Yellow (return) G.t. to playfield
WC
N/C
Violet (return) G.L to playfield
N/C
White-Orange (6.8VAC) to hood
Wh~e-Yellow (6.SVAC) 10 playfield
N/C
White-Violet (6.SVAC) to playfield
J127
-1
Brown-Black (sol.
9
drive) to playfield coil
J127 - 2
N/C
J127 - 3 Brown -Red (sol.
1 0
drive) to playf ield coil
J127 - 4 Brown-Oranqs (sol. 11 drive) to playfieJd coil
J127 - 5 Brown-Yellow (sol.
12
drive) to playfield coil
J127 - 6 Brown-Green (sol. 13 drive) to playfield coil
J127 - 7 Brown-Blue (sol. 14 drive) to pJayfield coil
J127 - 8 Brown-Violet (sol. 15 drive) to playfield coil
J127 - 9 Brown-Gray (sol. 16 d rive) to playfield coi I
J122 - 1 Blue-Brown (sol. 25 drive) to playfield flashlamp
J122 - 2 Blue-Red (sol. 26 drive) to playfield flashlamps
J122 - 3 Blue-Orange (sol. 27 drive) to playfield flash lamp
J122·4 Blue-Yellow (sol. 28 drive) to playfield Motor EMI Brd
J122 - 5
N/C
J128 -1
N/C
J122 - 6
N/C
J128 _ 2
N/C
J122-7N/C
JI2S-3N/C
J122 - 8
N/C
J128 _ 4
N/C
J122 - 9
N/C
J128 _ 5 NJC
FISH TALES
3-32
•
