A4: MPU MODULE
COMPONENT PARTS LIST
REFERENCE
BALLY
ITEM
DESIGNATION
PART
#
DESCRIPTION
1
A4{see note 1)
AS-2962-25
MPU Module Complete.
2
A4 (see note 2)
AS-2518-35
MPU Module less Program
Memory, U1·6
lnct.
3-32
See Schemat ic
Resistors, See schematic for value
33
C14, C15
E-00586-006 7 Capacitor, 470 PFD, 1kv
34
C18
E-00586-0088
Capacitor, .05 MFD, 16V
35
C16
E-00586-0081
Capacitor,.1 MFD, 100V
36
C4,C5
E-00586-0073
Capacitor, 4.5 MFD, 25V
37
C3, C6-C13, C17, C81
E-00586-0085
Capacitor, .01 MFD, 25V
38
C79, C41-C67
E-00586-0083
Capacitor, 470 PFD, 50V
39
C19-C31, C78, C33-C40
E-00586-0082
Capacitor, 390 PFD, 50V
-
40
C1, C2, C68-C77
J~.•
OO586-OO8_4
Capacitor, 820 PFD, 50V
41
C32
~?~,
E-00586-0077 -Capacitor,
3000 PF, 1kv
43
05
E-00585-0023
Transistor PNP (MPS-3702)
44
Q1,Q2
E-00585-0031
Transistor (2N3904)
47
CR44
E-00587 -0006
Diode (lN4004)
48
CR1-CR7, CR11-CR43,
E-00587·0014
Diode (IN4148)
CR45-CR49
49
CR8
E-00679
LED (Green)
50
VR1
E-00598-0008
Diode Zener (8.2V, IN9598)
52
L1,L2
E-00604-0003
Inductor, 22 Micro Hy.
53
U12
E-00620-0004
Timer (555)
54
U19
E·00620·0005
Quad 21nput (4011)
55
U9
E-00620-0028
MPU I.C. (6800)
56
U10, U11
E-00620·0029
PIA I.C. (6820)
57
U7
E-00620-0030
RAM I.C. (6810)
59
U20
E-00620-0032
HEX Buffer I.C. (14502B)
60
U14,U18
E-00620-0033
HEX Inverter (4049B)
61
U15
E-00620-0034
Quad Memory Drive (MC3459L)
62
U16
E-00620·0035
Dual Monostable (9602)
-
64
U17
E-00620-0041
Quad 21nputs (74LOON)
65
U8
E-00620-0042
RAM (C MOS, P5101L-3)
68
BT1, BT2, BT3
E-00628-0003
Battery
70
S33
E-00658-0001
Push Button Switch
71
S1-S8, S9-S16, S17-S24,
E-00677
DIP Switch
S25-S32
73
E~00712
24 Pin Socket
74
E-00712-0001
40 Pin Socket
75
E-00712-0003
22 Pin Socket
77
J2
E-00715
15 Pin Wafer Connector
78
J1
E-00715-0004
28 Pin Wafer Connector
79
J3, J5
E-00715-0017
16 Pin Wafer Connector
80
~4
E-00715-0018
19 Pin Wafer Connector
81
J5
E-00715-0024
17 Pin Wafer Connector
NOTE
1:
--'
When ordering, fill in dash number. For example, AS-2962-0: LOST WORLD, AS-2962-2: SIX MILLION DOLLAR
MAN, AS-2962-3: PLAYBOY, AS-2962-4: VOLTAN, AS-2962-5: SUPERSONIC, AS-2962-6: STAR TREK,
AS-2962-7: KISS, AS-2962-8: PARAGON, AS-2962-9: GROUND SHAKER, AS-2962-10: HARLEM .GLOBE-
TERS, AS~2962-12: DOLLY PARTON,AS~2962-13:SILVERBALL MANIA, AS-2962-18: MYSTIC, AS-2962-20
HOTDOGGIN, AS-2962-22: SKATEBALL, AS-2963-23: FRONTIER, AS-2962-21: XENON, AS-2962-24:
FLASH GORDON, AS-2962-26: EIGHT BALL DELUXE, AS-2962-25: FIREBALL II.
NOTE 2: Order replacement memory chips U1-U6, specifying game, socket and part number stamped on chip.
