GAME #1219 FIREBALL II (FIGURE V)
SOLENOID IDENTIFICATION TABLE
Self
Test
#
SOLENOID IDENTIFICATION
01 OUTHOLE KICKER
02
KNOCKER
03
LEFT THUMPER BUMPER
04
RIGHT THUMPER BUMPER
05
BOTTOM THUMPER BUMPER
06
LEFT SLINGSHOT
07
RIGHT SLINGSHOT
08
4 DROP TARGET RESET (LEFT)
Self
Test
#
SOLENOID IDENTIFICATION
09
3 DROP TARGET RESET
10
4 DROP TARGET RESET (RIGHT)
11
OOIN SAUCER
12
WOTAN SAUCER
13
POST KICKER
14
COIN LOCKOUT DOOR
15 KI RELAY (FLIPPER ENABLE)
16
FIREBALL RELAY (FIREBALL UNIT ENABLE)
SWITCH ASSEMBLY SELF-TEST DISPLAY NUMBERS
--
Switch
Switch
Self
Self
Test
#
DESCRIPTION
Test
#
DESCRIPTION
01
OUTHOLE
21
RIGHT
4
DROP TARGET "D" (BOTTOM)
02
# 1 LEFT OF OUTHOLE
22
RIGHT
4
DROP TARGET "C"
03 #2
LEFT OF OUT HOLE
23
RIGHT
4
DROP TARGET "B"
04
WOTAN SAUCER
24
RIGHT
4
DROP TARGET "P\' (TOP)
05
ODIN SAUCER
25 10
POINT REBOUND
(3)
06
CREDIT BUTTON
26
ODIN & WOTAN TARGET (RIGHT)
07
TILT
(3)
27
ODIN & WOTAN TARGET (MIDDLE)
08
FIREBALL RELAY SWITCH *
28
ODIN & WOTAN TARGET (LEFT)
09
COIN III (RIGHT)
29
LEFT
4
DROP TARGET "D" (TOP)
10
COIN I (LEFT)
30
LEFT
4
DROP TARGET "C"
11
COIN" (MIDDLE)
31
LEFT 4 DROP TARGET "B"
12
"0" LANE
32
LEFT 4 DROP TARGET
"ft:'
(BOTTOM)
13
"C" LANE
33 3
DROP TARGET (RIGHT)
14
"B" LANE
34 3
DROP TARGET (MIDDLE)
15
ow.'
LANE
35 3
DROP TARGET (LEFT)
16 SLAM
(2)
36
RIGHT SLINGSHOT
17
POST KICKER BUTTON (CAB.)
37
LEFT SLINGSHOT
18
#1 RIGHT OF OUTHOLE
38
BOTTOM THUMPER BUMPER
19
RIGHT OUTLANE
39
RIGHT THUMPER BUMPER
20
LEFT OUTLANE
40
LEFT THUMPER BUMPER
~.
*PUSH RELAY IN BY HAND
NOTE: SLINGSHOT & THUMPER BUMPER COILS
WILL BE ENERGIZED WHEN SWITCH IS MADE.
