Flip Up Targets
Flip Up Targets Assembly
C-12922
ITEM DESCRIPTION PARTNUMBER
1 Bracket, Flip Up
01-9274
2 Top Flip Up Target
03-8305
3 Switch
5674-12073-30
4 Switch Bracket
01-8774
5 Mach. Screw,
4006-01003-03
6-32 x 3/16
6 Bottom Target
01-9275
7 Retaining "E" Ring 20A-8712-14
----_. --_._------_- ._-_
Plastic Cover
03-8322
3
4
2
2-30 FUp Up Targets
Flip Up Reset Coli Assembly 8-12916
ITEM DESCRIPTION PARTNUMBER
1
Bell Armature
Assy
A-6306-l
2 Coil Assy
AE-26-1200
3 Kicker Mounting
B-12917
BracketAssy
4 Coil Retaining Brkt
01-8-508-T
5 Coil Tubing
03-7067-2
6 Coil Plunger Spring 10-135
7 Rubber Grommet
23-6313-1
8 Mach. Screw,
4008-01017-05
8-32 x 5/16, P-RH-S
Standup Target Assembly 8·11696-4
ITEM DESCRIPTION PARTNUMBER
1 Standup Target
B-11696-4
Assy Complete
2 Standup Target Sw SW-lA-I 70-4
3 Standup Target,
03-8093-4
Red
4 Diode,lN4001 l.OA 5070-06258-00
