I. INSTALLATION
Assemble the game as follows:
Bolt legs to cabinet. Bolt back box to cabinet. Use
flat washers under bolt heads. Gently feed cable
connectors and ground braid through cable port in
back box. Screw ground braid to braid in back box.
Carefully and fully insert connectors on printed
circuit assemblies .
On all games there ae certain items that should be
checked after shipment.
These are visual
inspections which may avoid time consuming
service work later. Minor troubles caused by
abusive handling in shipment are unavoidable.
Cable connectors may be loosened, switches
(especially tilt switches) may go out of adjustment.
Plumb bob tilt switch should always be adjusted
after game is set on location and leg levelers are
adjusted.
Visual inspections before plugging in line cord:
1. Check that all cable connectors are completely
seated on printed circuit assemblies .
2. Check that cables are clear of all moving parts.
3. Check for any wires that may have become
disconnected.
4. Check switches for loose solder or other foreign
material that may have come loose in shipment
and could cause shorting of contacts.
5. Check wires on coils for proper soldering. Cold
solder connections may not show up in factory
inspection, but vibration in shipment may break
contact.
6. Check that fuses are firmly seated and making
good contact.
7. Check the transformer for any foreign material
shorting across wiring lugs.
8. Check wiring of transformer to correspond to
location voltage. See figure 1.
Check adjustment of the two (normally open) tilt
switches:
1. Plumb bob tilt on left side of cabinet near front
door.
2. Ball tilt above plumb bob tilt. Insert the smaller
ball (15/16" dia.) into the ball tilt assembly, and
adjust the bracket so the ball will roll free to con-
tact the switch blade, if front of cabinet is raised.
TRANSFORMER CONNECTION
INSTRUCTIONS
REFER TO BACK BOX WIRING DIAGRAM
IN GAME MANUAL FOR TABLE
"A"
Figure 1.
115 VAC, 2-8, 3-6, 7-10
120 VAC, 2-8,4-6,7-11
220 VAC, 4-8,7-9
240 VAC, 4-8, 7-11
PART OF POWER TRANSFORMER MODULE
LOCATED IN BACK BOX
