XIII. ABBREVIATED PARTS LIST
EIGHT BALL CHAMP
MIDWAY
PART
MISCELLANEOUS NUMBER
Transformer (Domestic or Export) ....................•............• MTOO-00141-000
Bulbs, #555 ~ .. ,. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. 0017-00003-0501
Lamp Socket w/Diode (IN4004) 0017-00031-0052
Lamp Socket w/Diode (IN4004)..................................... 0017-00031-0053
Lamp Socket w/Diode (IN4004) 0017-00031-0054
Lamp Socket w/o Diode............ 0017-00031-0055
Lamp Socket w/o Diode 0017-00031-0056
Lamp Socket w/o Diode 0017-00031-0058
Fuse, 1 Amp.3 AG Slow Blow (Playfield Solenoid Protection) 0017-00003-0103
Fuse, 3A, 3 AG Slow Blow 0017-00003-0007
Fuse, 6A, 3 AG 0017-00003-0008
Front Molding Assy. A360-00086-0000
Keypad Assy A365-00074-0000
Back Glass. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. OA42-00914-00XF
Ball Shooter Rod & Spring Assy. (Cabinet).. . . . . . . . . . . . . . . . . . . . . . . .. A360-00280-0000
Plumb-Bob: Tilt 0360-00900-0000
Keyhook: Door .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. .. 0017 -00009-0019
Credit Pushbutton - Red/White (Cabinet) 0017-00042-0684
Overlay - Start Button (Cabinet) 0365-00121-0000
Pushbutton - Orange (Cabinet) (2) 0151-00804-0011
Back-Box: Hinged Front 0365-00517-0400
Playfield Support 0360-00114-00XF
Allen Wrench: 1/8"........ . . . . .. . 0017-00009-0551
Ball: 1-1/16" Dia. Steel 0017-00009-0546
Ball: 15/16" Dia. Steel 0017-00009-0547
ASSEMBLY SWITCHES
Roll-over Button (3).. .. .. .. .. .. . .. . . .. . .. .. .. .. . .. . .. .. .. .. .. .. .... A360-00059-0000
Saucer .......•.................................................... A967-Q0075-0000
Credit Button (Cabinet) A365-00060-0100
Ball Heturn ............•........................................... 0017-00005-0183
Coin (2) (Door) 0017-00005-0195
Lane Change (Cabinet) A370-00078-0000
Rebound . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00069-0000
Right Sling Shot (2). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00069-0000
Left Sling Shot (2) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00069-0000
Thumper Bumper - Make (2) A967-00074-0000
Tilt (Cabinet) A360-00054-0000
Slam (Cabinet) A360-00076-0000
Tilt (Door) A090-00038-0000
Right Lanes (Out Lane & Ball Lane) (2) .. . . . . . . . . . . . . . . . . . . . . . . . . . .. A360-00069-0000
Left Lanes (Out Lane & Ball Lane) (2) A360-00069-0000
Flipper - Double Sw. - Make.. .. .. .. .. .. . .. . .. .. .. .. .. .. .. .. .. .. A365-Q0046-0000
Flipper - Double Sw. - Break. .. . .. .. .. . . .. . . .. . .. .. . .. . . .. .. .. . A365-00045-0000
Flipper - Break (2) . .. .. . .. . .. .. .. .. .. .. . . .. .. .. .. .. .. .. .. .. .. .. A365-00045-0000
Flipper - Make (2) (Cabinet) A360-oo071-0000
Back-Up Target ("E", "I", "Gil, "H", & "Til) (5) AB38-oo020-0000
Left Hand Single Drop Target (5) .. .. .. . . .. . . .. .. .. . . .. .. .. A360-00062-0000
Spinner " . . . . A360-00058-0000
Top Roll-over Lanes (3) . .. .. .. .. .. .. . .. . .. .. .. . .. .. .. .. .. .. . .. . . A360-00065-0000
1-23
BALLY
PART
NUMBER
E-120-198
E-120-200
E-120-201
E-120-186
E-120-188
E-120-210
E-133-44
A-3080-14
ASE-2378-5
E-138-3
P-1455-1
M-1718-7
M-168-26
M-168-50
ASW-A1-152
ASW-A1-209
ASW-A1-56
ASW-A1-47
ASW-A1-47
ASW-A1-47
ASW-A1-195
ASW-AO-13
ASW-A2-73
ASW-A1-47
ASW-A1-47
ASW-A1-61
ASW-A1-168
ASW-A1-151
ASW-A1-152
