EIGHT BALL CHAMP
~
SOLENOID IDENTIFICATION TABLE
SELF
SELF
•.
[JTEST
#
SOLENOID IDENTIFICATION
[J
TEST
#
SOLENOID IDENTIFICATION
i:
'>
01 Saucer
08 Drop Target 7,15
02 Left Thumper Bumper
09 Right Slingshot
03 Right Thumper Bumper
10 Left Slingshot
04 Drop Target 1,2,9,10
11 Outhole
05 Drop Target 3,11
12 Knocker
06 Drop Target 4,5,12,13
13 K1 Relay (Flipper Enable)
07 Drop Target 6,14
SWITCH ASSEMBLY IDENTIFICATION TABLE
i J i '
Switch
Switch
Self
Self
o
Test
#
DESCRIPTION
o
Test
#
DESCRIPTION
I
01 Right Thumper Bumper
20 "M" Top Lane
02 Left Thumper Bumper
21 "P" Return Lane
03 Right Slingshot
22 Not Used
04 Left Slingshot
23 Left Outlane
05 Saucer
24 Right Outlane
06 Credit
25 Drop Target 1,2,9,10
07 Rebound
26 Spinner
08 Outhole
27 Drop Target 3,11
09 Coin III (Right)
28 Drop Target 4,5,12,13
10 Coin I (Left)
29 Center Rollover Button
11 Coin II (Middle)
30 Drop Target 6,14
12 Left Rollover Button
31 Drop Target 7,15
13 Right Rollover Button
32 Lane Change (Cabinet)
14 Not Used
33 Drop Target "E"
15 Tilt
34 Drop Target "I"
-
J
16 Slam
35 Drop Target "G"
17 "C" Return Lane
36 Drop Target "H"
18 "H" Top Lane
37 Drop Target "T';
19 "A" Top Lane
/
~ f
1-18
