DR. DUDE
Backbox Parts
====
Item Part Number
Description
Item Part Number
Description
1
01-6645
Venting Screen
13 B-12704
Spkr Grillellogo Assy
2
B-1
0686-1 *
Knocker & Bracket Assy
a)
01-8996
Grille Speaker
3
A-12497
Upr Insert Bd Hinge Assy
b)
31-1493
Bally Logo
4
0-13336
PCB Plate Assembly
14 20-9637
Lock & Cam Kit
5
A-12498
Lwr Insert Bd Hinge Assy
15 0-11581-2016*
Audio Board Assembly
6
0-11883-2016*
System 11C CPU Board
16 0-12313-2016*
Backbox Interconnect Board
7
5100-0941 8-00
Bridge Rectifier, 100v, 35A.
17 0-13955
Speaker Panel Assy
a
5040-09051-00
Capacitor, 30,000 J.l.Fd,25v
a)
5555-12068-00
4" Piezo Spkr, 50W
9
A-13763-2016
DR. DUDE
Backbox
b)
5555-12015-00
an
Speaker, 6", 20W
10 0-12247-576*
Aux. Pwr Driver Board
** 18 2016-IN
Insert Assembly
11 01-9047
Insert Stop Bracket
a)
0-12502-1
Bally Right Display Bd
12 0-12246"
Power Supply Assembly
b)
0-12706
Bally Left Display Bd
* Refer to Individual Unit's Parts List
** Insert Assembly not shown in Backbox Parts Location
Diagram
Backbox Parts
2·34
..
