2016-PL-UP Mini-Playfield
Assembly
Item Part Number
Description
1 31-1002A-2016
Screened Playfield
2 A-12336~1
socket & Bulb Assy. (3 used)
24-8802
#906 Bulb 13V 0.69
3 A-14032
Socket & Bulb Assy. (3 used)
24-654.9
#44 Bulb
4 B-14077-2
Stand-Up Target - Green. (3 used)
5 SW-1A-170-2
Target Switch - Green (3 used)
6 B-14077-4
Stand-Up Target - Red (3 used)
7 SW-1A-170-4
Target Switch - Red (3 used)
8 B-14077-6
stand-up
Target - Yellow (3 used)
9
SW-1A.-170-6
Target Switch - Yellow (3 used)
10 01-9878
Switch Mounting Bracket (9 used)
2S-6652
Rubber Edge Protector
11 5070-06258-00
. Diode 1N4001, 1.0A (12.used)
12 C-13310-1
Motor EMI Assembly
13 03-8365-1
Plastic Post #8 - Red (sused)
14 . 23-6304
Rubber Bumper,
1-1/2"
ID (2 used)
15 23-6641
Rubber Bumper, .64" OD (2 used)
16 03-8435 -1
Plastic Gear 115 - Tr. Red
17 D-13793
Gear Assembly
(See p. 2-29)
18 .. 31-1006"2016-23
Screened Playfield Plastic
19 23-6551
Rubber Bumper
3/4
x
5/8 -
Yellow
Associated Assembly: D-13839 Mix Master Shroud Assy. (See p. 2-28)
20 A-13839
ShrolJd Assembly
03-8449
Plastic Shroud - Chrome
31-1592-2016-6
Glitter Decal - Gold
31-.1592-2016-7
Glitter Decal -'Gold
31-1592-2016-8
Glitter Decal - Gold·
31-1592-2016-9
Glitter Decal - Gold
21 20-9656-1
Fuel Line - Red
22 20-9656-2
Fuel Line - Green
23 20-9656-3
Fuel Line - Yellow
24 B-13840-9
Mix Master End Assy.
03-3450
Plastic End - Chrome
31-1592-2016-1
. Glitter Decal - Red
31-1592-2016-12
Glitter Decal - Red
25 B-13840-11
Mix Master End Assy.
03-8450
Plastic End - Chrome
31-1592-2016-3
.Glitter Decal - Green
31-1592-2016-4
Glitter Decal - Green
31-1592-2016-11
Glitter Decal - Green
26 B-13840-16
Mix Master End Assy.
03-8450
Plastic End - Chrome
31-1592-2016-2
Glitter Decal - Yellow
31-1592-2016-5
Glitter Decal - Yellow
31-1592-2016-13
Glitter Decal - Yellow
l
27 03-8149-9
Mini Dome - Tr. Red
28 03-8149-11
Mini Dome - Tr. Green
29 03-8149-16
Mini Dome - Tr. Yellow
30 31-1006-2016-25
Screened Plastic Cover
Cable Assemblies (Not shown):
H-13906
H-13907
H-13908
H-13990
Mix Master Switch Cable
Mix Master Lamp Cable
Mix MasterFlash Lamp Cable
Motor Driver Cable
Mix
Master
2-26
