C-13~50
4-8ank Drop Target Assembly
DETAIL"N'
Item Part Number
Description
Item Part Number
Description
1 C-13451
Bracket
&
Stud Assembly
10 03-8036
Target, Plain
2 A-11397
Stop Bracket Assembly
11
20-8712-25
"E"-Ring, 1/4" Shaft
3 4408-01119-00
Nut, #8-32 ESN
12 4700-00072-00
Flatwasher, 17/64 x 1/2 x 21 gao
4 AE-24-900
Coil Assembly
13
10-392
Spring-Compression
5 03-7066-4
Coil Tubing, 2-3132" Lg.
14
10-364
Spring-Extension
6 A-13453
Reset Plate Assembly
15 23-6626
Rubber Grommet
a) 01-9547
Reset Plate, 4-Bank
16 C-12499
4-Bnk Drop Tgt Opto
b) 02-3972-1
Plunger
17
4700-00016-00
Flatwasher, 17/64 x 1/2 x 21ga.
c) 441 0-01132-00
Nut,
10-32
ESN
18 20-8712-18
"E"-Ring, 3/16" Shaft
7 01-9548 .
Bracket, Coil Mounting
19 03-8334-4
Target Stop, 5-3;·16"
8
4008-01016-10
Mach. Screw, 8-32 x 5/8
20 4004-01005-04
Mach. Screw,
4-40
x 1/4
9 4408-01128-00
Nut, #8-32 KEPS
Associated Parts:
31-1463-2016
4-8ank Drop Target Decal
4·Bank Drop Target
2·22
