0-12502 ..1
Bally Right Display Board
J3
J4
1
1,--=J6---111 " ""
"fo .. ~;,
..II" ..
II
,,~1....
~"I
DO DO
Part Number
Designation No.
Description
Qty.
5043-0S980-00
B (Bypass Cap)
Axial Cap., 0:01 Jlfd, 50v, (+80, -20%)
9
5043-08996-00
C1
Axial Cap., o.tutd, 50v, (+80, -20%)
1
5040-09343-00
C2
Axial Cap., 1Oufd, 25v, (±20%)
1
5075-09135~00
D1, D2
Zener, 1N4740, 10v
2
. 5670-12308-00
DSPL1
Display, 16-Character AIN
1
5791-10869-09
J1,J2,J5
9-Pin Header, Right Angle, .156
3
5791-10851-00
J3
26-Pin Header, Right Angle, .100
1
5791-10869-06
J7
6-Pin Header, Right Angle, .156
1
5010-08981-00
R39, R41, R43, R47, R53,
Resistor, 10Kn, 112w, 5%
9
R66,R70,R72,R84
5010-08773-00
R1-R8, R21-R37
Resistor, 18Kn,
·1/4w, 5%
25
5010-09162-00
R38, R40,R42,R44
Resistor,100Kn,
1/4w, 5%
32
R46,R48,R50,R52,R54-
R61,R63, R65, R67,R69
R71, R73, R75-R83, R85
5010-10258-00
R86
Resistor, 1Mn,
1/4w, 5%
1
5010-10927-00
R45,R49,R51,R62
Resistor, 8.2Kn,
1/4w, 5%
7
R64, R68, R74
5010-09534-00
W3,W4
Resistor, on
2
531 0-08975-00
U1-U3
I.C.4049
3
5310-09882-00
U6, U7, U10, U11
I.C.4001
4
5680-08969-00
U8,U9
I.C. 7180, Cathode Driver
2
5680-08968-00
U12,U13
I.C. 6118, Anode Driver
2
5768-12378-00
Bally-La Display PCB
1
03-8088-1
S (Support)
Support Display
5
16-8850-251
Label
1
2-11
Right Display
