0-12247-576 Auxiliary Power Driver Board
J6 1
L- __
---I
100000 .• 0001
J11
1
1000000000
.• 001
J12
1
10000 .• 00000001
Part Number
Ckt Designator
Description
5763-12184-00
Bare PC Board
5040-09537-00
C1, C3
Capacitor, 100 ufd., 100v, Radial
5040-12181-00
C5,C6
Capacitor, 10 utd., 100v, Radial
5043-09072-00
C2,C4
Capacitor, 0.1 J.1fd.,500v
5010-09160-00
R1 - R8
Resistor, 220n, 1/4w C.F., 5%
5012-12238-00
R9
Resistor, 3.3Kn,
sw,
10%
5010-09534-00
W1, W3, W4, W6
Resistor, on
5017-12180-00
VR1, VR2
Varistor, 100v
5100-09690-00
BR1, BR2
Bridge Rectifier, 35A, 200v
5070-08785-00
01 - 023
Diode, 1N4003
5070-09045-00
031 - 046
Diode, MR501
5191-12179-00
01 -08
Transistor, TIP36C
5580-09555-01
K1
Relay, DPDT, 13A
5733-12060-01
Fuse Holder
5731-08665-00
F5, F6
Fuse,2A,S-B,250v
5731-09128-00
F2A, F3
Fuse, 2-1/2A, S-B, 250v
5731-09651-00
F1,F2C
Fuse,5A,S-B,250v
5731-09432-00
F4, F7, F8
Fuse,7A,S-B,250v
i
5791-10862-09
J1, J2, J4 - J6, J8
Connector, 9-pin Hdr, Sq Pin
,
5791-10862-07
J3,J7,J9
Connector, 7-pin Hdr, Sq Pin
J
5791-10862-12
J11,J12
Connector, 12-pin Hdr, Sq Pin
5791-10862-04
J10
Connector, 4-pin Hdr, Sq Pin
16-8850-292
PCB Label
Aux Power Driver
2-8
