Playfield Parts
Item Part No.
Description
Item Part No.
Description
1
C-13174-R
Lower Right Flipper
25 0-13812
Mixmaster Entrance Ramp
a)
20-9250-6
Flipper Paddle & Shaft
26 5647-12073-21
Score, Mlxmaster Ramp
2
8-12918
R. Flipper Ban Guide Assembly
27 12-6466-15
Wire Ban Guide Assembly
3
B-12665
R. Kicker Arm ("Slingshot")
28 B-11696-4
Standup Target (Red)
a)
B-11203-R-1
Coil & Bracket Assembly
29 C-12842-1
Jumper Bumper
4
C-13174-L
Lower Left Flipper
30 C-12842-1
Jumper Bumper
a)
20-9250-6
Flipper Paddle & Shaft
31 C-12842-1
Jumper Bumper
5
B-12919
L. Flipper Ban Guide Assem bly 32 0-13643
Back Panel Assembly
6
B-12665
L. Kicker Arm ("Slingshot")
33 C-13716
Excellent Ray Assembly
7
12-6923
Right (mixmaster) Wire Ramp
34 0-11335-1
L. Ban Popper Assembly
8
12-6922
Right (ball popper) Wire Ramp 35 C-13857
Ban Guide Assembly
9
C-13450
4-Bank Drop Target
36 12-6466-17
Wire Ban Guide Assembly
a)
C-12499
4-Bank Opto Board
37 B-11696-2
Standup Target (Green)
10 B-13861
Ban Guide Assembly
38 12-6466-5
Wire Ban Guide Assembly
11 12-6466-2A
Wire Ball Guide Assembly
39 12-6925
Left (ban popper) Wire Ramp
12 B-13922
Ban Guide Assembly
40 B-13520
Magnet
13 B-13409
Right Ban Gate
41 B-13856
Ban Guide Assembly
14 0-13858
Ban Guide Assembly
42 5647-12073-07
Enter, Mixmaster Ramp
15 0-11335-1
R. Ban Popper Assembly
43 B-11696-4
Standup Target (Red)
16 B-13862
Ban Guide Assembly
44 B-14034
Heart of Rock 'n' Ron Assembly
17 0-13839
Shroud Assembly
45 B-14060-5
Standup Target (White, A-F)
18 2016-PL-UP
Mini Playfield Assembly
46 B-11696-4
Standup Target (Red)
19 0-13793
Hypnotic Wheel
47 A-14098
Big Shot Assembly
20 B-14077-4
Standup Target (red)
48 B-14033
Gift of Gab
21 B-14077-6
Standup Target (yenow)
49 Parts below are located beneath Bottom Arch:
22 B-14077-2
Standup Target (green)
a)
B-8623
Upper Trough Baffle Assembly
23 0-13859
Ban Guide Assembly
b)
C-8235
Lower Trough Baffle Assembly
24 12-6942
Wire Ball Guide Assembly
c)
12-6542
Trough Baffle Wire
d)
01-3569-1
Ban Trough (runway)
e)
01-5575
Bottom Arch Mounting Bracket
f)
8-8039-2
Outhole Kicker Assembly
- g~--
C-9638
Shooter Lane Feeder
Playfleld Pans
2-44
-------
