A-8039-3 Outhole Kicker Assembly
I'
,
I
,
I
I
,
"~
, , , ,
<,
, ,
li
<,
..•..
'"
,
<,
4
<,
'"
..•..
'"
'"
'"
Item Part Number
Description
1.
A-6378
2.
03-7066
3.
A-6889
4.
A-8038
5.
AE-27-1200
6.
03-7176-1
7.
10-101-4
8.
20-8712-25
9.
4006-01003-03
10.
A-8335
a) 02-2364
b) 20-8716-5
c)
01-4251
Mounting Plate Assembly
Coil Tubing
Kicker Lever Assembly
Coil Stop Assembly
Coil Assembly
Striker Ring
Spring-Reset
"E" Ring, 1/4" Shaft
Mach. Screw, 6-32 x 3/16"
Coil Plunger Assembly
Coil Plunger
Roll Pin,
1/8
x
7/16"
Ball Return Link
DOCTOR WHO 2-20
