A-15205-R-4
A-15205-L-4
Item Part Number
1.
B-13104-R
'" B-13104-L
2.
SW-1A-193
3.
4701-00002-00
4.
,·4105-01019-10
5.
4008-01079-05
6.
4701-00003-00
7.
01-9375
8.
20-6516
9.
4010-01066-06
10.
4701-00004-00
11.
A-12111
12.
FL-15411
a) 03-7066-5
13.
01-7695
14.
4006-01017-04
15.
10-364
16.
B-13882-R
'" B-13882-L
a) B-13884-R
'" B-13884-L
b) A-10656
c) 02-4179
d) 4010-01086-14
e) 4700-00023-00
f)
4701-00004-00
g) 4410-01132-00
17.
23-6577
18.
03-7568
19.
4006-01005-06
20.
4406-01117-00
Fliptronic II Flipper Assembly
(Lower Right)
Fliptronic II Flipper Assembly
(Lower Left)
Description
Flipper Base Assy, Right
Flipper Base Assy, Left
Switch Assembly
Lockwasher, #6 Split
Sh. Metal Screw, #5 x 5/8 P-RH-A
Mach. Screw, 8-32 x 5/16 H-SOC
Lockwasher, #8 Split
Switch Mounting Bracket
Speednut, Tinnerman
Cap Screw, 10-32 x 3/8, SH
Lockwasher, #10 Split
Flipper Stop Assembly
Flipper Coil (Orange)
Coil Tubing
Solenoid Bracket
Mach. Screw, 6-32 x 1/4 P-RH-S
Spring
Crank Link Assembly, Right
Crank Link Assembly, Left
Flipper Crank Assembly, Right
Flipper Crank Assembly, Left
Flipper Link Assembly
Link Spacer Bushing
Cap Screw, 10-32 x 7/8 SH
Flatwasher, 5/8 x 13/64 x 16ga.
Lockwasher #10 Split
Nut, 10-32 ESN
Bumper Plug, 5/8"
Flipper Bushing
Mach. Screw, 6-32 x 3/8 P-PH
Nut, 6-32 Hex.
Associated Parts for Left
&
Right Flippers:
21.
23-6678-7
22.
20-9734-6
Flipper Rubber (Red)
Flipper
&
Shaft (Yellow)
A-16090-L-4
Flipper Assembly
(Upper Left)
(Parts listed replace same items of A-15205-R-4)
Item Part Number
1.
A-16091-L
Associated Part:
22.
20-9250-6
Description
Flipper Base Assy, Left
Flipper & Shaft (Yellow)
Notes:
1.
'" Items for Left Flipper Assembly ONLY.
2. Each Flipper Assembly is mounted beneath the
playfield, in conjuction with the Plastic Flipper
&
Shaft,
and Flipper Rubber on the upper side of the playfield.
3. With the flipper, in the non-activated position,
the E.O.S. Switch contacts must have a gap of
.062 (±.015) inch. When flipper is activated switch
must close.
4. Any adjustment of the E.O.S. Switch must be made
at a minimum distance of 0.25 inch from the switch
body.
5. Longer blade of E.O.S. Switch must be straight.
Gap adjustment is done by adjusting shorter
blade.
6. All moving elements of the assembly must operate
freely without any evidence of binding.
7. Apply Loctite™ 242 when reataching screws to the
Flipper Stop Assy, the Solenoid Bracket, ana the
Flipper Bushing.
DOCTOR WHO 2-18
