Table of Contents
.,
Game Rules & Playfield Shots
A-N
Section 1 - Game Operation
&
Test Information
(System WPC) ROM Summary
1-1
Pinball Game Assembly Instructions
1-2
Pinball Assembly, Playfield Pitch Angle and Leg Levelers Detail
Game Control Locations
1-4
Game Operation
1-5
Game Check-out
'"
'"
1-6
Menu System Operation
1-9
Bookkeeping Menu
1-10
B.1 Main Audits & B.2 Earnings Audits
1-1 0
B.3 Standard Audits & B.4 Feature Audits
1-11
8.5 Histograms
&
B.6 Time-Stamps
1-13
Printouts Menu
1-14
Test Menu
1-15
T.1 Switch Edges & T.2 Switch Levels
1-15
T.3 Single Switch, T.4 Solenoid, & T.5 Flasher Tests
1-16
T.6 G.I., T.7 Sound and Music, T.8 Single Lamp, T.9 All Lamps,
T.10 Lamp and Flasher Tests
1-17
T.11 Display & T.12 Flipper Coil Tests
1-18
T.13 Trap DoorTest
1-19
T.14 Mini-playfield Test
1-20
Utilities Menu
,
1-22
U.1 Clear Audits, U.2 Clear Coins, U.3 Reset H.S.T.D.,
U.4 Set Time
&
Date,
&
U.S Custom Message
1-22
U.6 Set Game I.D., U.7 Factory Adjustments, U.8 Factory Reset,
& U.9 Presets
1-23
Game Difficulty Table for U.S./Canada/France
1-24
Game Difficulty Table for Germany/Europe
1-25
Preset Table U.S./Canada
1-26
Preset Table Germany/Europe, and France
1-28
U.10 Clear Credits & U.11 Auto Burn-In
1-29
Adjustment Menu
1- 30
A.1 Standard Adjustments
1-30
A.2 Feature Adjustments
1-34
A.3 Pricing Adjustments
1-40
Pricing Table
1-42
A.4 H.S.T.D. Adjustments
1-43
A.5 Printer Adjustments
1-44
Error Messages
1-45
CPU Board, Sound Board Error Codes
&
Opto Theory
1-47
LED List
1-48
Fuse List
1-49
Maintenance Information
1-50
Playfield Adjustments
1-51
Mini-Playfield Service Instructions
1-52
Notes
1-54
Section 2 - Game Parts Information
Line Filter/Cordset Chart
2-2
Cabinet Parts
2-3
Backbox Assembly
2-4
Fliptronic II Board
2-5
Audio Board
2-6
CPU Board
2-8
Power Driver Board
2-10
Dot Matrix Controller Board
2-12
