POWER DRIVER BOARD CONTINUED ...
J12S-1 Not Used
J 12S-2 Brown-Blue, Sol 14, to backbox
J12S-3 Not Used
J128-4 Key
J12S-5 Not Used
J135-1 Red-Brown, Row 1 to speaker panel lamp
J135-2 Red-Black, Row 2 to speaker panel lamp
J135-3 Key
J135-4 Red-Orange, Row 3 to speaker panel lamp
J135-5 Not Used
J135-6 Not Used
J135-7 Red-Blue, Row 6 to speaker panel lamp
J135-S Red-Violet, Row 7 to speaker panel lamp
J135-9 Red-Gray, Row S to speaker panel lamp
J 129 Not Used
J130-1 Violet-Brown, Sol 1 to playfield coil
J130-2 Violet-Red, Sol 2 to playfield coil
J130-3
Key
J130-4 Violet-Orange, Sol 3 to playfield coil
J130-5 Violet-Yellow, Sol 4 to playfield coil
J130-6 Violet-Green, Sol 5 to playfield coil
J130-7 Violet-Blue, Sol 6 to playfield coil
J130-S Violet-Black, Sol 7 to playfield coil
J130-9 Not Used
J136-1 Key
J136-2 Not Used
J136-3 Yellow/Gray, Col 8 to cabinet lamp
J131-1 Not Used
J131-2 Key
J131-3 Violet-Blue, to insert flasher
J131-4 Not Used
J131-5 Violet-Gray, to insert flasher
J137-1 Yellow-Brown, Colt to playfield lamps
J137-2 Yellow-Red, Col 2 to playfield lamps
J137-3 Yellow-Orange, Col 3 to playfield lamps
J 137-4 Yellow-Black, Col 4 to playfield lamps
J137-5 Yellow-Green, Col5 to playfield lamps
J137-6
Yellow-Blue, Col 6 to playfield lamps
J137-7 Yellow-Violet, Col 7 to playfield lamps
J137-S Key
J137-9 Yellow-Gray, Col 8 to playfield lamps
J132-1 Not Used
J132-2 Not Used
J132-3 Blue-Orange, to insert flasher
J132-4 Key
J132-5 Blue-Yellow, to insert flasher
J13S-1 Not Used
J138-2 Yellow-Red, Col 2 to speaker panel lamps
J13S-3 Yellow-Orange, Col 3 to speaker panel lamps
J13S-4 Yellow-Black, Col 4 to speaker panel lamps
J138-5 Not Used
J13S-6 Yellow-Blue, Col6 to speaker panel lamps
J
13S-7 Yellow-Violet, Col 7 to speaker panel lamps
J13S-8 Key
J138-9 Yellow-Gray, Col S to speaker panel lamps
J133-1 Red-Brown, Row 1 to playfield lamps
J133-2 Red-Black, Row 2 to playfield lamps
J133-3 Key
J133-4 Red-Orange, Row 3 to playfield lamps
J133-5 Red-Yellow, Row 4 to playfield lamps
J133-6 Red-Green, Row 5 to playfield lamps
J133-7 Red-Blue, Row 6 to playfield lamps
J 133-S Red-Violet, Row 7 to playfield lamps
J133-9 Red-Gray, Row 8 to playfield lamps
J134-1 Not Used
J134-2 Not Used
J134-3 Key
J134-4 Not Used
J134-5 Not Used
J134-6 Not Used
J134-7 Not Used
J134-S Not Used
J134-9 Red-Gray, Row 8 to cabinet lamp
poe,
Board Legend
J1-J6 CoinDoor InterfaceBoard
Jtxx PowerDriverBoard
J2xx CPUBoard
J5xx AudioBoard
J6xx Dot MatrixControllerBoard
J9xx F~tronlc II Board
DOCTORWHO 3-22
