LOWER PLAYFIELD PARTS
Item Part Number Description
1.
B-8925
Micro-Switch Plate Assembly
2.
A-15720
Kicker Assembly
3.
C-9638
Multiball Eject Assembly
10-128
Spring
B-9362-L-2
Coil & Bracket Assembly
4.
A-15205-R-4 Lower Right Flipper
5.
A-15205-L-4 Lower Left Flipper
6.
A-15680
Bi-Directional
Motor Drive Assy.
7.
B-12665
Kicker Arm (Slingshot) Assy. (2)
B-11203-R-1 Coil & Bracket Assembly
10-128
Spring
B-8284-1
Kicker Switch Assembly
8.
A-15429
5-Lamp Board Assembly
9.
A-15427
5-Lamp Board Assembly
10.
A-15428
6-Lamp Board Assembly
11.
A-15440
Cap Ball Popper Assembly
12.
01-10675
Ball Popper Ramp
13.
A-15441
Lower Ramp Assembly
14.
A-15424
15-Lamp Board Assembly
15.
A-9415-2
Jet Bumper Assembly (3)
B-12030-2
Switch & Diode Assembly (3)
16.
20006-PL-UP Mini-Playfield Assembly
a) A-15356
3-Door Assembly
J
b) A-15358
Ball Popper Assembly
(II)
c) A-15634
Motor & Cam Assembly
(II)
d) A-15358-1
Ball Popper Assembly
e) A-15581
Main Support Bracket Assembly
(II)
17.
A-14520
6-Lamp Board Assembly
18.
A-15641
Trap Door Assembly
10-399
Spring
A-15442
Cam & Plunger
A-15477
Switch Bracket Assembly
19.
A-15426
8-Lamp Board Assembly
20.
A-16090-L-4 Upper-Left Flipper
21.
A-15430
1O-Switch Opto PC Board
Underside of Playfield, Viewed in Raised Position
DOCTOR WHO
2-44
