Unique Parts List
Part Number
Description
Part Number
Description
A-12738-20006
WPC Sound Board
A-15641
Bracket & Coil Assembly
A-12742-20006
WPC CPU Board
A-15647
Tradis Assembly
A-13204-20006
Bottom Arch Assembly
A-15680
Bi-Directional Motor Drive Board
A-13769-20006
Playfield & Insert Assembly
A-15690
Right Ramp Assembly
A-13769-20006
Mini Playfield & Inset Assembly
A-15691
Cover/Sides Mini-Plfd Assy.
A-14376-20006
Backbox Assembly
A-15719
Shooter Gate Assembly
A-15035
Cam Assembly
A-15720
Kicker Bracket Assembly
A-15036
Support Bracket Assembly
A-15742
4-Lamp Board
A-15037
Main Bracket Assembly
A-15748
Cover Assembly
A-15309-1
2-10W Resistor PCB Assembly
A-15805
7-Lamp Board
A-15340
Motor EMI w/Brake Assembly
A-15806
Interrupter Assembly
A-15354
Ball Return, Ramp Assembly
A-15823
Speaker/ Display Assembly
A-15355
Bracket Door Release Assy.
A-15827
Switch Gate Assembly
A-15356
3-Door Assembly
A-15831-4
Stationary Target Assy. - Op. Red
A-15358
Ball Popper Assembly
A-15832-4
Stationary Target Assy. - Op. Red
A-15358-1
Ball Popper Assembly
A-15862
Standup Target & Decal Assy.
A-15424
15-Lamp Board
A-15894
Double Flipper Opto Assembly
A-15426
8-Lamp Board
A-15894-1
Single Flipper Opto Assembly
A-15427
5-Lamp Board
A-15896
Switch Button & Cable Assembly
A-15428
6-Lamp Board
A-15903
Standup Target Assembly
A-15429
5-Lamp Board
A-15904
Switch Gate & Decal Assy.
A-15430
Opto Switch 10-PCB Assy.
A-16191
Dalek Light Assembly
A-15431
5-0pto PCB Assembly
A-16199
Dalek Assembly
A-15432
5 LED PCB Assembly
A-8552-20006
Back Glass Assembly
A-15436
Main Ramp Assembly
A-15438-L
Flipper Ball Guide Assembly, Left
02-4252-25
F-F Spacer 6-32 x 9/16"
A-15438-R
Flipper Ball Guide Assembly, Right
02-4657-1
Post 6-32 x 3.25 Mtg. Ramp
A-15439
6-Target Assembly, Opaque Red
02-4677
Rubber Bumper Post #10
A-15440
Cap Ball Popper Assembly
02-4678
Double Bumper Post #10
A-15441
Lower Ramp Assembly
02-4679
Bumper Post #10
A-15442
Cam
&
Plunger Assembly
A-15443
Cam
&
Stop Pin Assembly
03-7960-20006
Mylar Playfield Set
A-1544
Gate Assembly
A-15459-1
Cashbox Assembly
11-1066-20006
Wood Cabinet
A-15477
Switch Bracket Assemby
A-15500
5-Target Assembly
31-1002-20006
Screened Palyfield
A-15501
Back Panel Assembly
31-1 002A-20006 Screened Playfield
A-15551
Flap Assembly
31-1008-20006
Screened Bottom Arch
A-15581
Main & Support Bracket Assembly
31-1357-20006
Screened Translite
A-15582
Mini-Playfiled Cover Assembly
31-1420-20006
Screened Speaker Panel Cover
A-15604
Ramp Ball Popper Assembly
31-1681
Playfield Plastics Set
A-15631-4
Standup Target w/Decal - Op. Red
31-1685
Standup Target Decal Set
A-15634
Motor
&
Cam Assembly
31-1686
Decal Set - Top
A-15640-1
Playfield Plastic Assembly
31-1687
Decal Set - Bottom
A-15640-2
Playfield Plastic Assembly
31-1688
Decal Set - Top/Bottom (Small)
31-1708
Decal Set - Dome
DOCTOR WHO 2-41
