DRIVER BOARD (con't)
Pin Wire Color
Function
2P7 - LAMP ROW DRIVE
I
Red-Brown
Lamp Row
I
2 Red-Black
Lamp Row 2
3
Red-Orange
Lamp Row 3
4
. Red-Yellow
Lamp Row 4
5 Red-Green
Lamp Row 5
6
Red-Blue
Lamp Row
6
7 Key
Key
8
Red-Gray
Lamp Row 8
9 Red-Violet
Lamp Row 7
2P8 - LOGIC POWER BUS INPUT
1
2
3
4
5
6
7
8
9
Black
Black
Black
Black
Key
Gray
Gray
Gray
Gray
Logic Ground
Logic Ground
Logic Ground
Logic Ground
Key
Logic B+ (+5 VDC)
Logic B+ (+5 VDC)
Logic B+ (+ 5 VDC)
Logic B+ (+5 VDC)
2P9 - CABINET SOLENOIDS DRIVE
1
2
3
4
5
6
7
8
9
1,000 Point Sound (11)
10,000 Point Sound (12)
Not Used
Knocker (14)
Tilt Sound (15)
Coin Lockout
100 Point Sound (10)
Key
10 Point Sound (9)
Brown-Orange
Brown- Yellow
N/C
Brown-Blue
Brown- Violet
Brown-Gray
Brown-Red
Key
Brown-Black
)
2PIO - SOLENOID GROUNDS
1 Black
Solenoid Ground
2 Black
Solenoid Ground
3
Black
Solenoid Ground
4 Black
Solenoid Ground
5
Key
Key
6 N/C
Not Used
7 Black
Solenoid Ground
8 Black
Solenoid Ground
9 Black
Solenoid Ground
2Pll - PLA YFIELD SOLENOIDS
1
N/C
Not Used
2
N/C
Not Used
3
N/C
Not Used
4 Gray- Brown
Ball Release
5 Gray-Red
FEV Drop Target Reset
6
Key
Key
7 Gray-Orange
ER Drop Target Reset
8
N/C
Not Used
9 Brown-Green
Sound Alternator
NOTE: Number in parentheses ( ) in 2P9, 2P11, and
2P12 function column is the solenoid number
readout during test 02.
30
DRIVER BOARD (con't)
Pin Wire Color
Function
2P12 - SPECIAL SOLENOIDS DRIVE
1 Orange- Violet
Right Flipper Enable
2 Orange-Gray
Left Flipper Enable
3
Blue-Orange
Left Kicker Spec. 3 (19)
4
Blue-Red
Right Jet Bumper Spec. 2 (18)
5 Key
Key
6
Blue-Yellow
Right Kicker Spec. 4 (20)
7
Blue-Brown
Left Jet Bumper Spec. 1 (17)
8
N/C
Not Used
9
N/C
Not Used
2P13 - SPECIAL SWITCH INPUTS
1 Key
Key
2 Orange- Black
Special Switch 3
3 Orange-Red
Speeial Switch 2
4 Orange- Yellow Special Switch 4
5 Orange- Brown
Special Switch
I
6
N/C
Not Used
7
N/C
Not Used
8
N/C
Not Used
9
N/C
Not Used
POWER SUPPLY
3Pl - POWER BUS INPUTS
1 Violet
Lamps (+ 18 VDC)
2 Orange
Solenoids (+ 28 VDC)
3
N/C
Not Used
4 White
90 VAC
5
N/C
Not Used
6
N/C
Not Used
7
N/C
Not Used
8
N/C
Not Used
9 White
90 VAC
10 Gray
18.7 VAC
11 Gray
18.7 VAC
12 Gray-White
18.7 VAC C.T.
3P2 - POWER BUS INPUTS
1
N/C
Not Used
2
N/C
Not Used
3 Black
Solenoid Reel.
4
N/C
Not Used
5
N/C
Not Used
6
Black
Lamp Reel.
3P3 - DISPLAY LAMPS
&
SOLENOID POWER BUS
1
N/C
Not Used
2
N/C
Not Used
3
Black
Ground
4
N/C
Not Used
5
N/C
Not Used
6
Red
Solenoid B+ (+ 28 VDC)
7 Red
Solenoid B+ (+ 28 VDC)
8
N/C
Not Used
9
Key
Key
