FUSE LISTING.
The following fuses are used:
Part Number
Description
5730-09252-00 Fuse, 8A Slow-8low (S-8), 125v
5731-09651-00 Fuse, 5A S-8, 250v
5730-09071-00 Fuse, 8A S-8, 32v
5730-12203-00 Fuse, 1/10A S-8, 250v
5731-08665-00 Fuse, 2A S-8, 250v
5731-06314-00 Fuse, 4A S-8, 250v
5731-09651-00 Fuse, 5A S-8, 250v
5731-08761-00 Fuse, 1/4A S-8, 250v
5731-09432-00 Fuse, 7A S-8, 250v
5731-09128-00 Fuse, 2-1/2A S-8, 250v
Circuit/Location
Input Power ("high voltage") Line/Cabinet Box"
Gen. Illumination/Upper Rt Backbox fuseholder (4)
+18 Vdc Lamp Cktl Lwr Rt Backbox fuse holder (1)
+
& -
100V Display Pwr/Upr Cntr B'box fuseholder (2)
F1, F3 - F6; 0-11813 Aux Pwr Driver Board
F2, F7; 0-11813 Aux Pwr Driver Board
F8; 0-11813 Aux Pwr Driver Board
F1, 0-8345-557 Power Supply
F5, F6; 0-8345-557 Power Supply
+25Vdc Solenoid "A" cktlMid P'fld fuseholder (1)
• One 4A SoB, 250v fuse (5731-06314-00) is provided for an overseas (220v) game installation.
