A-19177
Back Panel Assembly
10
NOTE'
TIJISTEIIP""III:
GOCSTO L"'I'P
Item Part No.
Description
Item Part No.
Description
1.
A19006
Kickout Coil Assembly
12.
H-19171
Cable
2.
03-8149-9
Playfield Insert (Mini-Dome)
13.
B-12156
Lamp Assembly
3.
4808-01175-08 E-P #8 x
1/2"
IND-PL-HWH
14.
03-8022-5
Spacer, .343" Long
4.
A-19176
Ball Gate Actuator Assembly
15.
41 06-01115-12 Sh. Metal Screw, #6 x
3/4"
5.
A-17713
Three Lamp G.I. Assembly
16.
01-12569
Back Panel Gusset Brkt.
6.
A-17712
Two Lamp G.I. Assembly
17.
4008-01113-28 Mach. Screw, 8-32 x
1-3/4"
7.
4008-01168-10 Mach.Screw, 8-32 x
5/8"
18.
23-6694-3
Rubber Ring,
5/16"
8.
03-8063-6
Bulb Sleeve, Yellow
19.
03-8247-9
Bumper Post
9.
11-1215.3
Wood Panel
20.
03-7655-4
Clamp - Cable
1/4"
10.
4408-01118-00 Nut 8-32 Tee
3/8"
L.
21.
03-7655-8
Clamp - Cable
1/2"
11.
*31-1995-9
Back Panel Decal
* Not available for individual sale. Order decal set 31-1995.
2-32
