A-19242
Dual H-Drive Motor Controller
&
Bracket
Assy .
•
©
~~!~
8
gffiffi
I ~
D'~,:
G
I
0
C3
I~
1
0
o
1
0
o
10
1=
I
©I
2
Item Part No.
Designator
Description
1.
01-10756
Bracket
2.
07 -6688-18N
Rivet,
3/16
X
1/8"
•
3 .
A-19159
Dual H-Driver PCB Assy.
5040-10974-00 C1, C3
Cap., 100IlFd, 35v, Rad.
5043-08980-00 C2, C4-C9
Cap., 0.01IlFd, 50v, Ax.
5010-09999-00 R1
Res., 2Kn, 14w, 5%
5010-08991-00 R2, R3, R5, R8,
Res., 4.7Kn, 14w, 5%
R10, R16, R17, R19,
R22, R24
5010-09034-00 R4, R6, R7, R9, R11,
Res., 10Kn, 14w, 5%
R12, R18, R20, R21,
R23,R25,R26
5070-09054-00 01-018
Diode, 1N4004, 1.0A.
5162-12635-00
01, 03, 06, 08
Trans., TIP102, NPN
5192-12428-00
02, 04, 07, 09
Trans., TIP107, PNP
5370-12272-00 U1
IC, LM339, Ouad
5671-13732-00 LED1
LED Display RED
5551-09822-00 L1-L4
Inductor, 4.7IlH, 3A
5010-09534-00 JP1, JP2
Jumper, on
5791-12273-11 J1
Connector, 11-pin Header
5791-12273-04 J2, J3
Connector, 4-pin Header
•
2-13
