Fliptronic
II
Controller
~FoI
Boord
~~
[iJ~
Fuse List
Audio Boord
II
F1 0811
II
Fso11
II
Fs0211
Dot Matrix
Control ler
Boord
II
F60211
II
F6011
II
F11sl
II
F1 07111
F1 0911
II
F1 06111
F1
0
II
Audio Board
F501 -25V Circuit
F502 +25V Circuit
3A, 250V, S.B.
3A, 250V, S.B.
Dot Matrix Controller Board
F601 +62V Circuit
F602 -113V and -125V Circuits
3/8A, 250V, F.B.
3/8A, 250V, F.B.
Fliptronic II Controller Board
F901 Upper Right Flipper
F902 Upper Left Flipper
F903 Lower Right Flipper
F904 Lower Left Flipper
3A, 250V, S.B.
3A, 250V, S.B.
3A, 250V, S.B.
3A, 250V, S.B.
I
F11111
I
F11211
I
F1311
I
F141
Power
Driver Boord
Power Driver Board
F101 +50VDC General (Left Flipper) 3A, 250V, S.B.
F102 +50VDC General (Right Flipper) 3A, 250V, S.B.
F103 Solenoid #25-#28
3A, 250V, S.B.
F104 Solenoid #9-#16
3A, 250V, S.B.
F105 Solenoid #1-#8
3A, 250V, S.B.
F106 G.I. #5 Wht-Vio
5A, 250V, S.B.
F107 G.I. #4 Wht-Grn
5A, 250V, S.B.
F108 G.I. #3 Wht-Yel
5A, 250V, S.B.
F109 G.I. #2 Wht-Org
5A, 250V, S.B.
F110 G.I. #1 Wht-Brn
5A, 250V, S.B.
F111 Flasher Secondary
5A, 250V, S.B.
F112 Solenoid Secondary
7A, 250V, S.B.
F113 +5V Logic
5A, 250V, S.B.
F114 +18V Lamp Matrix
8A, 32V, N.B.
F115 +12V Switch Matrix
3/4A, 250V, F.B.
F116 +12V Secondary
3A, 250V, S.B.
Line Filter
Domestic Game
Foreign Game
1-41
8A
5A, S.B.
