ENGINE LEFT - This test moves the angular position of the engine to the left (counter-clockwise)
until the "FULL LEFT" optical switch closes.
ENGINE RIGHT - This test moves the angular position of the engine to the right (clockwise) until
the "FULL RIGHT" optical switch closes.
ENGINE CENTER - This test moves the angular position of the engine to the center. At this
point, neither the "FULL LEFT" nor the "FULL RIGHT" optical switches should be closed.
T.17 Race Test
Select T.17 from the Test Menu and press "ENTER" to begin the RACE TRACK
test. Once the "SELF TEST" completes successfully, the "UP" and "DOWN" buttons can be used
to select the following tests. Use the "ENTER" button to start the selected test, and the
"ESCAPE" button to abort the selected test.
The status of the "LEFT START", "RIGHT START", "LEFT ENCODER", and "RIGHT ENCODER"
optical switches and car positions are displayed on the dot matrix display during all tests.
SELF TEST - This test verifies that the race track is operational. This test is run automatically
upon entry to the RACE TEST. It can also be started manually by pressing the "ENTER" button
when selected.
LEFT HOME - This test drives the left car in reverse until the "LEFT START" optical switch is
closes.
LEFT FORWARD - This test drives the left car forward while the
"+"
button is pressed.
LEFT REVERSE - This test drives the left car in reverse while the "-" button is pressed .
RIGHT HOME - This test drives the right car in reverse until the "RIGHT START" optical switch is
closes.
RIGHT FORWARD - This test drives the right car forward while the
"+"
button is pressed.
RIGHT REVERSE - This test drives the right car in reverse while the "_" button is pressed.
T.18 Empty Balls Test
BALLS test.
Select T.18 from the Test Menu and press "ENTER" to begin the EMPTY
This test kicks out all balls loaded in troughs, lockups, poppers, and kickouts until no balls remain
in those locations.
Note: As the trough kicks out balls, they will stack up in the shooter groove, which may require
manual clearing in order to allow further balls to be kicked out.
1-17
