Sound Board
A-16917 -50036
P1 34-pin Ribbon Cable data to/from J601; J903;
J202
J3-1 Gray +5V from J 114-4; J904-1; J210-4
J3-2 Key
J3-3 Gray +5V from J114-3; J210-5
J3-4 Black ground from J 114-7; J904-4; J21 0-1
J3-5 Black ground from J 114-5; J904-5; J21 0-3
ID~DO!
I
J3
5
J1-1 Black-Yellow signal to cabinet speaker
J 1-2 Not Used
J1-3 Key
J
1-4 Black ground
rn
~
'--
.•..
•
o
-
J2-1 Black-Yellow signal to display panal speakers
J2-2 Key
J2-3 Not Used
J2-4 Black ground
[1] -
'--
-
-
J4-1 Gray-Green 18VAC from xfrmr secondary
J4-2 Gray-Green 18VAC loop from J4-1
J4-3 Key
J4-4 Gray 18VAC from xfrmr secondary
J4-5 Gray 18VAC loop from J4-4
J4-6 Gray-White 18VAC from xfrmr secondary
J4-7 Gray-White loop from J4-6
i---- - - l i --- - --
I
~
11
I
I
-
I
I
GJ
J1
I
I
I I
I
L
_gABlliEl_ __
J I
I
I
SOUND
I
1 - - - ---- - -1
I
BOARD
I
I I
I
I I
I
I
I
I
I
I
I
I
I
I
I
LSPEAKER_PANI_L
_ j
J2
L
J
3-33
