J127-1 Brown-Black 801 9 to playfield coil
J127-2 Key
J127-3 Brown-Red 80110 to playfield coil
J127-4 Brown-Orange 80111 to playfield coil
J127-5 Brown-Yellow 80112 to playfield coil
J127-6 Brown-Green 80113 to playfioeld coil
J127-7 Not Used
J127-8 Brown-Violet 80115 to playfield coil
J127-9 Brown-Gray 80116 to playfield coil
J 128 Not Used
J 129 Not Used
J130-1 Violet-Brown 8011 to playfield coil
J130-2 Violet-Red 8012 to playfield coil
J130-3 Key
J130-4 Violet-Orange 8013 to playfield coil
J130-5 Violet-Yellow 8014 to playfield coil
J130-6 Violet-Green 8015 to playfield coil
J130-7 Not Used
J130-8 Violet-Black 8017 to playfield coil
J130-9 Violet-Gray 8018 to playfield coil
J131 Not Used
J 132 Not Used
J133 Not Used
J134-1 Not Used
J 134-2 Not Used
J134-3 Key
J 134-4 Not Used
J 134-5 Not Used
J 134-6 Not Used
J 134-7 Red-Blue Row 6 to cabinet lamp
J134-8 Red-Violet Row 7 to cabinet lamp
J134-9 Red-Gray Row 8 to cabinet lamp
J 135-1 Red-Brown Row 1 to playfield lamps
J135-2 Red-Black Row 2 to playfield lamps
J135-3 Key
J 135-4 Red-Orange Row 3 to playfield lam ps
J135-5 Red-Yellow Row 4 to playfield lamps
J 135-6 Red-Green Row 5 to playfield lamps
J135-7 Red-Blue Row 6 to playfield lamps
J135-8 Red-Violet Row 7 to playfield lamps
J135-9 Red-Gray Row 8 to playfield lamps
J136-1 Key
J 136-2 Not Used
J136-3 Yellow-Gray Col8 to insert lamps
J137 Not Used
J138-1 Yellow-Brown Col 1 to playfield lamps
J138-2 Yellow-Red Col2 to playfield lamps
J138-3 Yellow-Orange Col 3 to playfield lamps
J138-4 Yellow-Black Col 4 to playfield lamps
J138-5 Yellow-Green Col5 to playfield lamps
J138-6 Yellow-Blue Col 6 to playfield lamps
J138-7 Yellow-Violet Col 7 to playfield lamps
J138-8 Key
J138-9 Yellow-Gray Col 8 to playfield lamps
