Power Driver Board
A-12697-3
1
91
7
8 '.,
e
c::l
~
J112
Jll1
J101-1 Red 9VAC from xfrmr secondary
J1 01-2 Red 9VAC from xfrmr secondary
J101-3 Key
J101-4 Blue-White 13VAC from xfrmr secondary
J101-5 Blue-White loop from J101-4
J101-6 Blue-White 13VAC from xfrmr secondary
J101-7 Blue-White loop from J101-6
J102-1 White-Red loop from J102-2
J102-2 White-Red 16VAC from xfrmr secondary
J102-3 White-Red loop from J102-4
J102-4 White-Red 16VAC from xfrmr secondary
J102-5 Black-Yellow loop from J102-6
J102-6 Black-Yellow 16VAC from xfrmr secondary
J102-7 Key
J102-8 Black-Yellow loop from J102-9
J102-9 Black Yellow 16VAC from xfrmr secondary
J 103 Not Used
J104-1 White-Blue 50VAC to J901-1,2
J104-2 White-Blue 50VAC to J901-3,5
J104-3 Key
J 104-4 Not Used
J 104-5 Not Used
J 105 Not Used
1 3 1
5
Bleeo.ol
vice
Jl05
Jl07
,B.
lfl§
Jl05
.••
lllJ
-W
~ =
,
0
, N
!
•
c
J106-1 Not Used
J 106-2 Not Used
J 106-3 Not Used
J106-4 Key
J106-5 Red-White +20V to insert flash lamps
J107-1 Not Used
J107-2 Red-Brown 50V to playfield coils
J107-3 Red-Black 50V to playfield coils
J107-4 Key
J107-5 Not Used
J107-6 Red-White +20V to playfield flashlamps
J
108 Not Used
J
109 Not Used
J110 Not Used
J111 Not Used
J112-1 White-Green 9.8VAC from xfrmr secondary
J112-2 White-Green loop from J112-1
J112-3 White-Green 9.8VAC from xfrmr secondary
J112-4 Key
J112-5 White-Green loop from J112-3
3-29
