Opto SW10
=.c.a.
A-18159
J1-1 Gray-Violet to A-18617 Jl-7 Sw #37
Jl-2 Gray-Blue to LED Sw #36
Jl-3 Gray-Green to LED Sw #35
Jl-4 Gray-Black to A-18617 Jl-3 Sw #34
Jl-5 Gray-Orange to A-18617 Jl-4 Sw #33
Jl-6 Gray-Red to A-18617 Jl-5 Sw #32
Jl-7 Gray-Brown to A-18617 Jl-6 Sw #31
Jl-8 Key
Jl-9 Black Ground to A-18617 Jl-9
J2-1 Orange-Violet to A-18618 Jl-3 Sw #37
J2-2 Orange-Blue to Photo Transistor Sw #36
J2-3 Orange-Green to Photo Transistor Sw #35
J2-4 Orange-Yellow to A-18618 J 1-7 Sw #34
J2-5 Orange-Black to A-18618 Jl-6 Sw #33
J2-6 Key
J2-7 Orange-Red to A-18618 J 1-5 Sw #32
J2-8 Orange-Brown to A-18618 Jl-4 Sw #31
J2-9 Gray-Yellow +12VDC to A-18618 J1-1
J3-1 Black Ground from J116-3
J3-2 Gray-Yellow +12VDC from J116-2
J3-3 Green-Yellow from J207-4
J3-4 Green-Orange from J207-3
J3-5 Key
J3-6 White-Violet from J209-8
J3-7 White-Blue from J209-7
J3-8 White-Green from J209-5
J3-9 White-Yellow from J209-4
J3-10 White-Orange from J209-3
J3-11 White-Red from J209-2
J3-12 White-Brown from J209-1
J4-1 Gray-Orange to LED Sw #43
J4-2 Not Used
J4-3 Not Used
J4-4 Key
J4-5 Orange-Black to Photo Transistor Sw #43
CPU
BOARD
J113
J116
POWER DRIVER BOARD
to
0
rn~
*0
ill
0
J
0
(_
0
L()
0
0
0
UI
l()
to
J
0
0
0
*
(_
m~
0
N
0
"<t
0
J
0
J3
0
L()
0000000*0000
12
J5-1 Gray-Red to LED Sw #42
J5-2 Not Used
J5-3 Key
J5-4 Not Used
J5-5 Orange-Red to Photo Transistor Sw #42
J6-1 Gray-Brown to LED Sw #41
J6-2 Key
J6-3 Black Ground
J6-4 Gray-YellOW +12VDC
J6-5 Orange-Brown to Photo Transistor Sw #41
r:::--:-c:-c----::-iP
LA
YFI
Er=-LD---,-;c:-:::-----.,----.
Photo Tronsis!or Boord
LED Boord
Jl
OPTO SW10 P.C.B.
A-18159
J4
J5
J6
~~ ~~
"0 "0
~g
g~
g3Qg
3-18
