FLASHER WIRING
J1 07 @} Red-White +20VDC
J106@]- Red-White +20VDC
.•.
I 1
ZR-1 ZR-1 Right Rear Right
Ramp Underside Panel Standup
Sol 25 Sol 26 Sol 27 Sol 28
~ Blue-Brown I 1
1
2 Blue-Red
J124 3 Blue-Oranqe
5 Blue-Yellow
L___
POWER r T
DRIVER Tenth Right Upper Lef Catch
BOARD Corvette Ramps Flipper Me
Sol 20 Sol 22 Sol 23 Sol 24
~ Blue-Yellow I 1
5
7 Blue-Black
J125 8 Blue-Violet
Blue-Gray INSERT FLASHERS
9
L__
-- ~---------------------------------------------------------
I 1
ZR-1 ZR-1 Right Rear Right
Ramp Underside Panel Standup
Sol 25 Sol 26 Sol 27 Sol 28
~ Blue-Brown I
I 1
2 Blue-Red
J122 3 Blue-Oranqe PLAYFIELD FLASHERS
4 Blue-Yellow
'-
I 1
Jets Right Upper Lef Catch
Ramps Flipper Me
Sol 21 Sol 22 Sol 23 Sol 24
- Blue-Green I
I 5
6 Blue-Black
J126 7 Blue-Violet
8 Blue-Gray
L__
3-7
