UPPER PLAYFIELD PARTS
Item Part Number
Description
No.
1 01-9211
Playfield Hanger Bracket (2)
43 A-19004
* Race Track Assembly
2 B-11873
Bottom Arch Kicker Assy.
44 A-18591
Ball Guide
3 A-15849-L -2
Lower Left Flipper Assembly
45 A-17794
Kicker Switch Sub-Assembly
20-9250-5
Flipper & Shaft, White
46 A-18982
Spinner Gate Assembly
4 A-17791
Kickback Micro Switch Assy.
47 02-5108
5/16" Standoff
5 A-19208-2
Flipper Ball Guide, Left
48 A-19007
Loop Ramp Assembly
6 12-7231
Right Lane Wire
49 01-13020
Ball Guide
7 A-H811
Slingshot Kicker Assembly
50 01-13021
Ball Guide
B-9362-R-3
Coil & Bracket Assembly
51 A-19009
Race Track Ramp Assembly
10-128
Spring
52 A-17226-4
Rectangle Target, Red
8 A-17801
Kicker Count Switch Assy.
53 12-7213
Center Wire Ramp
9 12-7214
Left Wire Ramp
54 A-18589
Ball Guide
10 02-5107
Adjustable Post (2)
55 A-18590
Ball Guide
11 A-19221
3-Bank Drop Target Assembly
56 A-18019-4
Square Target, Red
12 A-18988
3-Bank Rubber Switch Assy.
57 A-17794
Kicker Switch Sub-Assembly
13 01-13023
Ball Guide
58 A-19259
* Race Tree Lamp & Bracket
14 A-H611
Kicker Count Switch Assy.
01-13223
Race Track Bracket
15 A-15849-L
Upper Left Flipper Assembly
59 A-19260
Right Wire Ramp Assembly
20-9250-5
Flipper w/Shaft, White
60 A-17811
Slingshot Kicker Assembly
16 A-18588
Ball Guide
B-9362-L-2
Coil & Bracket Assembly
17 A-19162
* Plastic Exhaust Pipe
10-128
Spring
18 12-7215
Garage Wire Ramp
61 A-17813
Rollover Switch Assembly
19 A-16816-4
Oblong Target, Red
62 A-19208-1
Flipper Ball Guide, Right
20 01-13022
Ball Guide
63 A-19223-R
Right Flipper Assembly
21 A-19154
Exhaust Pipe Assembly
20-9250-5
Flipper & Shaft, White
22 A-15368-1
Eject Assembly
64 A-18753
Ball Trough Assembly
A-17985-R
Eject Switch Assembly
65 A-18973
Shooter Lane Switch Assy.
23 A-18975
Garage Guide Weld Assembly
66 01-13273
Bottom Arch Ball Guide
24 A-19003
2-Switch & Bracket Assembly
67 A-18593
Ball Guide
25 A-19005
Popper Assembly
68 A-18587
Ball Guide
26 A-19156
Engine Plastic Bracket
69 01-13413
Right Lane Divider
27 A-18594
Ball Guide
70 A-19521
Bump Gate Assembly
28 A-19140
Engine & Ramp Assembly
A-19332
LT-5 Engine Wire Assembly
29 03-8318-9
Light Hood, Red (4)
Miscellaneous
30 A-17796
Ball Gate Actuator Coil Assy.
A-13204-50036
Bottom Arch Assembly
31 A-19001
Ball Gate Special Assembly
A-13769-50036
Screened Playfield
32 01-12569
Gusset Bracket (2)
A-19314-1
Playfield Plastic Assembly
33 01-13296
* Left Corner Bracket
A-19314-2
Playfield Plastic Assembly
34 A-19176
* Ball Gate Actuator Assembly
A-19314-3
Playfield Plastic Assembly
35 A-19006
Kickout Coil Assembly
A-19316
Ramp Cover Assembly
36 A-19177
Back Panel Assembly
A-19317
Ramp Cover Assembly
37 01-13297
* Right Corner Bracket
01-13298
Car Light Baffle (Ioc. on insert)
38 A-19151
Upper Loop Switch Assembly
03-9295-1
**Full Playfield Mylar
39 A-18592
Ball Guide
03-9295-2
Ramp Drop Area Mylar
40 A-17241
Ramp Diverter Assembly
03-9295-3
Ramp Drop Area Mylar
A-18977
Diverter Flag Rivet Assembly
03-9295-4
Exhaust Drop Area Mylar
20-8712-25
E-ring, 1/4" Shaft
03-9295-5
Jet Bumper Area Mylar
4700-00072-00 Flat Washer
20-6500
Steel Ball 1 1/6" (4)
41 A-18967
Ball Guide
42 A-9415-2
Jet Bumper Coil Assembly (3)
B-12030-2
Jet Bumper Switch Assy. (3)
"Not Shown
B-9414-3
Jet Wafer Assy., Red (3)
**The Corvette hardcoat playfield does not require a
03-8254-9
Jet Bumper Cap, Red (3)
full mylar. However, mylars can be purchased through
your local Bally Distributor.
2-40
