Item Part Number
Description
Item Part Number
Description
1 AE-25-1000
Coil Assembly
18 01-14206.1
Gray Gorilla Return Arm
2 A-18957
Stop Bracket Assembly
19
10-362
Spring
3 02-5245.1
Ball Deflector Rod
20
02-5244
Gray Gorilla Plunger
4 A-20603
Lamp Board Assembly
21
04-10094-1
Reflector & Socket Assembly
5 4408-0111 9-01 Nut 8-32 ESN
22
01-3670
Switch Plate Curved
6 31-2530
Plastic Liner
23
01-8657
Switch Limit Stop
7 07-6704-04
Pop Rivet, 1/8 x
14"
24
31-2531-1
Decal
8 4008-01168-06
Mach. Screw, 8-32 x 3/8"
25
31-2531-2
Decal
9
20-8712-25
"E" Retaining Ring,
1/.1"
Shaft
26
03-9454
Tie-Wrap, 4" Long
10 4700-00033-00
Flat Washer, 17/64 x
3/.1
x 15ga.
27
H-18219-1
Cable
11 07-6688-27
Rivet, 1/8 x 9/16"
28
H-20734.1
Cable
12 SW-1 A-203-6
Target Switch
29
03-7066
Coil Tubing
13 A-20681
Gray Gorilla Shaft Sub-Assy.
30
23-6684-2
Edge Protector, %" Long
~
14 04-10324.1
Gray Gorilla Pan
31
12-6227
Hairpin Clip
p
15 04-10330.1
Gray Gorilla Bearing Bracket
32
01-14282
Ball Stop
16 01-14204
Gray Gorilla Return Stop
33
4700-00080-00
Flat Washer, 25/64 x
%
x 16ga.
17 01-14205.2
Gray Gorilla Actuator Arm
2-29
•
I
j
p..
A-20614
Gorilla Assembly
