Bottom Arch Kicker Assembly
Item Part Number
Description
1 A-6306-2
Bell Armature Assembly
2 AE-23-800
Coil Sub-Assembly
3 01-11273
Mounting Bracket
4 01-8-508-T
Solenoid Bracket
5 03-7067-5
Coil Tubing
6 10-135
Solenoid Spring
7 23-6420
Rubber Grommet
8 4008-01017 -04 Mach. Screw, 8-32 x
1/4"
9 03-8523
Insulator
-(j)
A-17932-1
Disappearing Post Assembly
Item Part Number
Description
1 01-12441
Diverter Post Bracket
2 03-7067-5
Coil Tubing
3
01-8-508-T
Coil Retainer Bracket
4 AE-27-1200
Coil Sub-Assembly
5 10-135
Spring
6 A-17986
Bell Armature Assembly
7 23-6420
Rubber Grommet
8 4008-01017 -04 Mach. Screw, #8-32 x
W'
