Press the Up or Down buttons to cycle through the menu. Press the Enter button to access an
adjustment. Press the Up or Down buttons to see the setting choices. Press the Enter button to lock in a
setting choice. If a mistake is made, press the Escape button while "Saving Adjustment Value" is in the
display. The original value is retained and the new value is ignored. Press the Escape button to return to
the Adjustment Menu.
A.
ADJUSTMENTS MENU
A.1 Standard Adjustments
A.2 Feature Adjustments
A.3 Pricing Adjustments
A.4 H.S.T.D Adjustments
A.5 Printer Adjustments (optional board required)
A.1 Standard Adjustments
A.1 01 Balls Per Game
A "game" is defined by specifying the number of balls to be played.
Range: 1 to 10.
A.1 02 Tilt Warnings
The number of total actuation's of the plumb bob that can occur before the game is "tilted".
Range: 1 to 10.
A.1 03 Maximum Extra Balls
The number of Extra Balls that a player may accumulate.
Range: 0 to 10.
A.1 04 Maximum Extra Balls/Ball in Play
The number of Extra Balls to be awarded per ball in play.
OFF
No maximum number of Extra Ball per ball in play.
1-10
1 through 10 Extra Balls per ball in play.
A.1 05 Replay System
The type of replay system to be used.
Fixed - Replay value is set and does not change during game play.
Auto
% -
Replay starting value is set but changes every 50 games to comply with the
percentage of replays desired.
A.1 06 Replay Percent*
The percentage of replays the players are able to earn when Auto Replay is used.
Range: 5% to 50%.
A.1 07 Replay Start*
Replay start value when Auto
%
Replay is used.
Range: 15,000,000 to 250,000,000.
A.1 08 Replay Levels*
The number of replay levels used by the Auto
%
Replay mode. The range of this setting is 1 to
4. When two replay levels are chosen, the second replay level is automatically adjusted to twice
the starting replay level. When three of four replay levels are chosen, their values are
automatically adjusted to three or tour times the starting replay level.
'For Auto
%
Replay
1-21
