GAME CONTROL LOCATIONS
Cabinet Switches
The On-Off Switch is on the bottom of the cabinet near the right front leg.
The Start Button is a push-button to the left of the coin door on the cabinet exterior. Press the Start
button to begin a game, or during the diagnostic mode, to ask for HELP.
Coin Door Buttons
The operator controls all game adjustments, obtains bookkeeping information, and diagnoses problems,
using only four push-button switches mounted on the inside of the coin door. The coin door buttons have
two modes of operation Normal Function and Test Function.
Normal Function
The Service Credits button puts credits on the game that are not included in any of the game audits.
The Volume Up (+) button raises the sound level of the game. Press and hold the button until the
desired level is reached.
The Volume Down (-) button lowers the sound level of the game. Press and hold the button until the
desired level is reached. See Adjustment A.1 28 to shut sound Off completely.
The Begin Test button starts the Menu System operation and changes the coin door buttons trom
Normal Function to Test Function.
Test Function
The Escape button allows you to get out of a menu selection or return to the Attract mode.
The
1J.Ql+)
button allows you to cycle forward through the menu selections or adjustment choices.
The Down (-) button allows you to cycle backward through the menu selections or adjustment
choices.
The *Enter button allows you to get into a menu selection or lock in an adjustment choice.
/ '
/ '
/
/
/
/ C():n Doer
Ku::or]
I
I
~'on l
Moloi'1g
J-~76 15
S:wt
BUlton _.eeoc
LO 966.3--1
\
I
\
[ =S:AP[
. -_ . -
- -~ - '-I W ERl!
I
\
I
-,SI \1()[;~ H.J~CTIO'l
_j
I
I
\
/
\
-,
/
/ '
/ '
. /
Lever Cu de Assem bly
A-167 7J- 1
---_
-_
-
.-
__
.
-------.._ilipper Butto",· Ye low
A-1688.3-6
Boll
S~ootE~,
Assemby
B1244~
I
c:;1 Swikr
')/4909
*To reset High Score, hold down the Begin Test/Enter switch for five seconds while in the Attract
mode.
1-6
